Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 3000 x 970 x 850 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Leg height | 150 mm | |
| Per-seat width | 700 mm | |
| Seat depth | 680 mm | |
| Backrest height | 400 mm | |
| Under-seat clearance | 130 mm | |
| End panel width | 120 mm | |
| Individual segment depth | 680 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total seating capacity | 4 people | |
|---|---|---|
| Per-seat static load capacity | 100 kg | |
| Net product weight | 180 kg | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Structural warranty | 3 years | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 30 kg/m³ | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Primary upholstery fabric | Light blue woven commercial polyester | |
|---|---|---|
| Accent panel upholstery | Black matte woven fabric | |
| Seat padding | High resilience polyurethane foam | |
| Back padding | High resilience polyurethane foam | |
| Internal frame | Kiln-dried solid wood + engineered wood | |
| Support legs | Chrome-plated 10mm diameter steel hairpin legs | |
| Seam construction | Reinforced stitched seams with 8mm stitch pitch | |
| Modular connection hardware | Zinc-plated steel connecting brackets | |
| Seat support deck | 12mm thick plywood panel with 50mm elastic webbing | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Modular segment connection | Bolts and steel brackets lock 4 segments into fixed J-curve layout | |
|---|---|---|
| Armless open design | No integrated armrests to maximize seating capacity per linear length | |
| Elevated leg design | 150mm metal hairpin legs create open under-seat space | |
| Fixed upright back angle | 105 degree backrest tilt for upright waiting posture | |
| Two-tone accent finish | Black end panels create visual contrast for modern reception aesthetics | |
| Upholstery cleanability | Stain-resistant fabric surface allows spot cleaning with mild detergent | |
| Floor protection | Each leg fitted with 20mm non-slip rubber foot cap | |
| Custom layout compatibility | Segments can be adjusted to form alternate curved radii on order | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Office lobby reception areas | Curved J-shape creates natural gathering space for waiting visitors | |
|---|---|---|
| Corporate waiting lounges | Commercial grade upholstery and load rating suit high daily visitor traffic | |
| Public service center waiting zones | Armless open layout maximizes seating capacity for high-occupancy spaces | |
| Medical clinic patient waiting areas | Smooth upholstery surface supports regular cleaning and hygiene protocols | |
| Hotel lounge check-in areas | Two-tone modern design complements contemporary hospitality interiors | |
| Co-working space common areas | Modular curved layout supports casual collaboration and short-term seating |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Strength, durability and safety requirements for non-domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture flammability test for cigarette ignition resistance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Performance standard for lounge and public area seating, applicable to load and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to inner frame strength testing | |
|---|---|---|
| GB 20400-2006 | Limits of harmful substances in leather and fabric upholstery, applicable to formaldehyde testing | |
| GB/T 10357.1-2013 | Mechanical test methods for furniture, applicable to static and impact load testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to inner frame strength testing; 2. GB 20400-2006: Limits of harmful substances in leather and fabric upholstery, applicable to formaldehyde testing; 3. GB/T 10357.1-2013: Mechanical test methods for furniture, applicable to static and impact load testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
