Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions (sofa only) | 3400 x 1480 x 780 mm | |
|---|---|---|
| Single seat module dimensions | 680 x 740 x 780 mm | |
| Seat height from floor | 420 mm | |
| Seat cushion depth | 580 mm | |
| Backrest height above seat | 360 mm | |
| Armrest width (end units only) | 80 mm | |
| Leg height from floor | 120 mm | |
| White square side table dimensions | 600 x 600 x 520 mm | |
| Black integrated laptop side table dimensions | 450 x 350 x 620 mm | |
| Clearance beneath sofa and tables | 100 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total sofa unit net weight | 192 kg | |
|---|---|---|
| Per-seat static load capacity | 160 kg | |
| Total maximum seated user capacity | 6 adults | |
| Seat foam compression set rating (reference) | <=10% after 25000 cycle loading | |
| Upholstery fabric abrasion resistance | 50000 Martindale cycles | |
| Seat foam compression set rating | 10% after 25000 cycle loading | |
| Seam tensile strength | 180 N | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest upholstery | Woven polyester contract fabric in olive green and charcoal grey two-tone scheme | |
|---|---|---|
| Seat cushion core | 40kg/m3 high-density polyurethane foam | |
| Backrest cushion core | 30kg/m3 medium-density polyurethane foam | |
| Internal seat frame | 18mm thick plywood structural frame with reinforced corner blocks | |
| Sofa support legs | 30mm diameter polished chrome-plated steel cylindrical legs | |
| White side table tops | 25mm thick matte white painted MDF with rounded edge profile | |
| Black laptop side table top | 8mm thick tempered black safety glass with polished edge | |
| Side table support frames | 20mm diameter polished chrome-plated square tubular steel frames | |
| Seam construction | 10 stitches per 100mm matching thread upholstery seams | |
| Levelling feet | 20mm diameter adjustable plastic glides on each leg base | |
| Seat support system | 80mm wide elastic webbing spaced 80mm apart across the seat frame, secured with steel staples | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% |
Adjustment / rotation / tilt / mobility / storage features
| Modular reconfiguration capability | Individual seat units connect via underside metal joining brackets, allowing layout changes to linear, L-shape or custom back-to-back configurations | |
|---|---|---|
| Back-to-back space division function | Dual-sided backrest arrangement creates a physical space divider for open-plan offices, separating seating zones without full-height partitions | |
| Integrated side table placement | Three freestanding side tables nest between seat modules to provide beverage and device surfaces without blocking seating access | |
| Cable management accessibility | 100mm open floor clearance beneath seats allows power and data cables to be routed between wall outlets and table surfaces without drilling into sofa units | |
| Stain resistant upholstery treatment | Fabric is factory treated with a water-repellent coating to resist liquid spills from coffee, tea and water, standard for commercial lounge applications | |
| Tool-free leg installation | All metal legs attach via pre-installed hanger bolts, requiring only hand tightening for on-site assembly to reduce installation time | |
| Floor protection function | Plastic glides on all leg bases prevent scratching of hard flooring including tile, vinyl and polished concrete, and can be replaced with felt glides for hardwood surfaces | |
| Seat cushion non-slip design | Cushions are secured to the seat frame with hook-and-loop fasteners to prevent sliding during regular use | |
| Cable routing clearance | 100mm open floor clearance beneath seats allows power and data cables up to 20mm diameter to be routed between wall outlets and table surfaces without drilling into sofa units | |
| Cushion non-slip fixation | Seat and back cushions are secured to the frame with 50mm wide hook-and-loop fasteners at four anchor points per cushion to prevent sliding during sit/stand transitions | |
| Anti-tip stability | All seat modules include 2kg steel anti-tip weights secured to the rear base frame, preventing tipping when users lean on backrest edges at maximum 160kg per-seat load | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total knock-down package count | 9 packages | |
|---|---|---|
| Sofa module carton dimensions | 720 x 780 x 500 mm per unit, corrugated cardboard with protective foam corner wrapping | |
| Side table carton dimensions | 660 x 660 x 120 mm per white table, 510 x 410 x 120 mm for the black laptop table, flat-pack construction | |
| Total gross shipping weight | 230 kg | |
| Total shipping volume (CBM) | 2.1 CBM | |
| On-site assembly time | 90 minutes | |
| 40ft HQ container loading quantity | 56 complete sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm |
Recommended spaces / users / usage modes
| Office reception and waiting areas | Two-tone modular layout provides 6 guest seats, ideal for corporate lobbies, client waiting zones and reception spaces where professional, durable seating is required | |
|---|---|---|
| Open-plan breakout and collaboration spaces | Back-to-back configuration divides open office space into small work and relaxation zones, with integrated side tables for laptops, beverages and meeting materials | |
| Co-working facility common areas | Reconfigurable modular design allows co-working operators to adjust seating layout to suit events, workshops or regular daily use, with durable components that withstand high turnover of users | |
| Educational institution faculty and student lounges | Mid-back support and stain-resistant fabric suits long-duration seating in university or college lounge spaces, with sufficient clearance for accessible movement around units | |
| Healthcare facility waiting zones | Chrome legs and smooth fabric surfaces allow easy cleaning and disinfection between patients, with stable load rating to support a wide range of adult users | |
| Recommended complementary configuration | Pair with optional matching ottoman units and USB-integrated side tables to add device charging capability and extra flexible seating for larger groups | |
| Short-stay business center guest areas | Modular seating and integrated side tables support temporary guest use in hotel business centers and airport lounge zones, with tool-free assembly enabling quick setup and reconfiguration for changing guest volumes |
EU Market Access Requirements* EN Standards
| EN 13759:2012 applicability | Domestic and contract furniture – Seating – Test methods for strength and durability, applicable to all seat frame, backrest and leg structural components | |
|---|---|---|
| EN 1021-1:2014 applicability | Furniture – Assessment of the ignitability of upholstered furniture – Ignition source smouldering cigarette, applicable to all fabric and foam upholstery components | |
| EN 1021-2:2014 applicability | Furniture – Assessment of the ignitability of upholstered furniture – Ignition source match flame equivalent, applicable to all fabric and foam upholstery components | |
| EN 12521:2015 | Furniture – Strength, durability and safety requirements for non-domestic seating, applicable to all structural components of the sofa set; defines minimum performance thresholds for high-use commercial seating environments |
Standards applicable to China-market projects
| GB/T 3324-2017 applicability | General technical requirements for wooden furniture, applicable to the internal plywood framing of all sofa seat modules | |
|---|---|---|
| GB 18580-2017 applicability | Formaldehyde emission limits for wood-based panels, applicable to all plywood and MDF components used in sofa frames and tabletops | |
| GB/T 1952.1-2012 applicability | General technical requirements for sofas, applicable to upholstery, foam padding, structural strength and durability of all sofa units |
This product must meet the following technical requirements: 1. GB/T 3324-2017 applicability: General technical requirements for wooden furniture, applicable to the internal plywood framing of all sofa seat modules; 2. GB 18580-2017 applicability: Formaldehyde emission limits for wood-based panels, applicable to all plywood and MDF components used in sofa frames and tabletops; 3. GB/T 1952.1-2012 applicability: General technical requirements for sofas, applicable to upholstery, foam padding, structural strength and durability of all sofa units; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
