Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint | 2800 x 2200 x 700 mm | |
|---|---|---|
| Single L-shaped sofa unit dimensions | 1200 x 1000 x 700 mm | |
| Seat height from floor | 450 mm | |
| Seat depth per unit | 600 mm | |
| Backrest height above seat | 250 mm | |
| Armrest width | 200 mm | |
| Cylindrical ottoman dimensions | 450 mm diameter x 450 mm height | |
| Round pedestal side table dimensions | 600 mm diameter x 500 mm height | |
| Throw pillow dimensions | 450 x 450 mm | |
| Seat cushion thickness | 150 mm | |
| Back cushion thickness | 120 mm | |
| Plinth base height | 100 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Per-seat static load capacity | 150 kg | |
|---|---|---|
| Overall set total weight capacity | 900 kg | |
| Foam density (seat core) | 35 kg/m³ | |
| Foam density (back core) | 28 kg/m³ | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance | 50000 Martindale cycles | |
| Frame service life (commercial use) | 10 years | |
| Set net weight (total) | 200 kg | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal frame | Kiln-dried solid hardwood skeleton, 30mm section thickness | |
|---|---|---|
| Seat filling | High-density polyurethane foam, 150mm thickness | |
| Back filling | Medium-density polyurethane foam, 120mm thickness | |
| Upholstery fabric | Stain-resistant woven polyester fabric, 350g/m² weight | |
| Plinth base | Plywood substrate wrapped in matching upholstery fabric, floor-level finish | |
| Ottoman construction | Internal plywood frame, foam padding, matching upholstery | |
| Side table top | Matte white solid surface / sintered stone top, 20mm thickness | |
| Side table base | Powder-coated tapered steel pedestal base, blue finish | |
| Throw pillows | Polyester fiber fill, removable matching upholstery covers | |
| Seam construction | Reinforced stitched seams, 8 stitches per inch pitch | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Modular reconfiguration | Units connect via hidden metal clip connectors, adjustable layout arrangements | |
|---|---|---|
| Fixed static seating | No recline, tilt or adjustable mechanisms, fixed padded support | |
| Supplementary ottoman seating | Cylindrical ottomans provide extra flexible seating or footrest positions | |
| Plinth base stability | Full floor-contact base eliminates wobble, no leg adjustment required | |
| Removable cushion covers | Zippered upholstery covers on seat and throw pillows for cleaning | |
| Noise-free placement | Felt floor protection pads pre-installed under base to prevent floor scratches | |
| Color customization support | Two-tone color options available for upholstery to match interior schemes | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Office reception and waiting areas | Conversational facing layout suitable for guest seating in corporate lobbies | |
|---|---|---|
| Hotel lounge and public waiting zones | Durable commercial construction suitable for high-traffic hospitality spaces | |
| Modern residential open-plan living rooms | Minimalist blocky design fits contemporary home interior styles | |
| Co-working space casual collaboration areas | Flexible modular layout supports small group discussions and informal meetings | |
| Healthcare facility waiting zones | Stain-resistant upholstery allows easy cleaning for public health environments | |
| Recommended configuration | Place table centrally between sofa units, position ottomans for flexible extra seating |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture - Strength, durability and safety for domestic seating | |
|---|---|---|
| EN 1022:2018 | Furniture - Seating - Determination of stability | |
| EN 14465:2005 | Upholstery fabrics - Specification for woven fabrics for furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge and public seating standard for strength and durability | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | General office chairs - reference for static load testing methodology |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal frame quality | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission control | |
| GB/T 19801-2005 | Upholstered furniture furniture classification and performance requirements | |
| GB/T 29894-2013 | Safety requirements for upholstered furniture, applicable to structural stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal frame quality; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission control; 3. GB/T 19801-2005: Upholstered furniture furniture classification and performance requirements; 4. GB/T 29894-2013: Safety requirements for upholstered furniture, applicable to structural stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
