Product supplierModular L-shaped Fabric Sofa with Throw Pillows, Light grey matte woven fabric
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2800 × 1800 × 750 mm | |
|---|---|---|
| Backrest height above seat | 330 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total net weight | 120 kg | |
|---|---|---|
| Maximum distributed static load | 450 kg | |
| Seat cushion foam density | 40 kg/m³ | |
| Backrest foam density | 28 kg/m³ | |
| Fabric abrasion resistance (Martindale) | 30000 cycles | |
| Seat cushion rebound rate | 60% | |
| Recommended maximum occupancy | 3 adults | |
| Frame static load rating | 600 kg | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat upholstery | Light grey matte woven fabric | |
|---|---|---|
| Backrest upholstery | Dusty blue matte woven fabric | |
| Seat cushion core | High-density polyurethane foam | |
| Backrest cushion core | Medium-density polyurethane foam | |
| Internal frame | Kiln-dried solid wood + plywood | |
| Seat support base | Elastic webbing + sinuous spring | |
| Throw pillow covers | Matching woven fabric, removable | |
| Throw pillow filling | Hollow polyester fiberfill | |
| Bottom base cover | Tight woven fabric skid-resistant base | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Modular connection | Hidden metal clip connectors between seat units | |
|---|---|---|
| Double-sided backrest design | Central shared backrest supports seating on both sides | |
| Throw pillow adjustability | 4 removable, positionable throw pillows | |
| Tool-free assembly | Modular units connect without specialized tools | |
| Low-profile floor clearance | 0 mm floor gap, sofa sits directly on finished floor | |
| Seat orientation flexibility | Supports left or right chaise configuration | |
| Removable cushion covers | Zippered cushion and pillow covers | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office lounge and breakout area | Low-profile modular seating for casual employee breaks and informal meetings | |
|---|---|---|
| Bay window and open waiting space | Double-sided backrest fits placement near windows with views on both sides | |
| Co-working common space | Reconfigurable layout adapts to changing event and seating needs | |
| Modern residential living room | Minimalist low-profile design matches contemporary light neutral interior styles | |
| Reception waiting zone | Open seating structure accommodates flexible guest flow in small reception areas |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture stability standard | EN 12520:2015 | |
|---|---|---|
| Upholstered furniture flame resistance | EN 1021:2014 | |
| Formaldehyde emission standard | EN 717:2004 |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Upholstered furniture safety standard | GB/T 3324 | |
|---|---|---|
| Formaldehyde emission limit | GB 18584 | |
| Fabric colorfastness standard | GB/T 3920 |
Standardized tender description text
This product must meet the following technical requirements: 1. Upholstered furniture safety standard: GB/T 3324; 2. Formaldehyde emission limit: GB 18584; 3. Fabric colorfastness standard: GB/T 3920; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
