Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 5000 x 2200 x 790 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Individual seat depth | 600 mm | |
| Seat width per modular segment | 600 mm | |
| Backrest height above seat | 340 mm | |
| Backrest thickness | 120 mm | |
| Base plinth height | 100 mm | |
| Integrated round side table diameter | 600 mm | |
| Side table height above floor | 450 mm | |
| Throw pillow dimensions | 300 x 300 mm | |
| Per-module upholstered outer edge width | 800 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total seating capacity | 10 persons | |
|---|---|---|
| Per-seat static load rating | 150 kg | |
| Overall static load rating | 1500 kg | |
| Seat foam density | 45D | |
| Foam rebound rate | 60% | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Product net weight | 380 kg | |
| Commercial frame warranty | 5 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal frame | Kiln-dried solid pine + 15mm plywood, moisture content 12% | |
|---|---|---|
| Seat support layer | 3.2mm serpentine springs + 50mm elastic webbing | |
| Seat cushion filling | 45D high-resilience polyurethane foam, 120mm thick | |
| Backrest filling | 35D soft polyurethane foam, 100mm thick | |
| Exterior upholstery | Commercial-grade polyester fabric, 0.8mm thick, stain-resistant finish | |
| Base plinth upholstery | Matching fabric-wrapped high-density foam, rigid internal backing | |
| Throw pillow filling | 100% polyester fiberfill, removable zippered covers | |
| Integrated side table top | 18mm white matte laminate, 25mm edge radius | |
| Side table support post | 50mm diameter powder-coated steel tube, matte white finish | |
| Modular connection hardware | Heavy-duty steel connecting brackets, zinc-plated | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide |
Adjustment / rotation / tilt / mobility / storage features
| Modular reconfiguration | Individual curved segments connect via steel brackets to form custom curved layouts | |
|---|---|---|
| Dual curved seating nooks | Two semi-enclosed inward-facing seating groups, each paired with a central side table | |
| Matching throw pillow support | Attached two-tone throw pillows provide adjustable back and neck support | |
| Freestanding floor installation | Rests directly on level finished floors without required wall or floor anchoring | |
| High-traffic upholstery performance | Stain and abrasion resistant fabric suitable for daily commercial public use | |
| Bundled side table integration | Two matching round pedestal side tables positioned at center of each seating nook | |
| Customizable layout option | Segments can be added or removed to adjust overall length and curve radius | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Office breakout areas | Semi-private nooks support informal collaboration and short rest breaks for staff | |
|---|---|---|
| Commercial reception lobbies | Distinctive curved shape creates visual focal point for waiting visitors | |
| Retail and public service waiting zones | High capacity seating accommodates fluctuating visitor flows | |
| Education campus common areas | Casual seating supports student group discussion and downtime | |
| Hotel and hospitality lounge spaces | Soft two-tone upholstery fits modern welcoming public interior designs | |
| Co-working space shared zones | Modular layout adapts to flexible open-plan space configurations |
EU Market Access Requirements* EN Standards
| EN 1335-2:2018 | Office furniture seating safety requirements, applicable for commercial public seating use | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance to smouldering cigarette ignition source |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge and public seating safety and durability performance standard | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for commercial product materials and emissions |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal frame construction | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture | |
| GB/T 19817-2005 | Upholstered furniture general technical requirements for seating durability and safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal frame construction; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; 3. GB/T 19817-2005: Upholstered furniture general technical requirements for seating durability and safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
