Automatic mm / inch conversion · Core engineering specifications
| Overall footprint (long axis x cross axis x seat height) | 3200 x 3200 x 450 mm | |
|---|---|---|
| Single seat module width | 800 mm | |
| Bench arm top surface depth | 400 mm | |
| Seat cushion thickness | 120 mm | |
| Side panel vertical height | 330 mm | |
| End module rounded corner radius | 100 mm | |
| Modular seam width | 10 mm | |
| Bench seat top surface depth | 400 mm | |
| Side body panel vertical height | 330 mm | |
| Central intersection module width | 800 mm | |
| Seat top upholstery overhang depth | 20 mm | |
| Base floor contact width per arm | 360 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Seated capacity (total) | 12 persons | |
|---|---|---|
| Unit weight range (per module) | 18 kg | |
| Distributed seat static load per module | 150 kg | |
| Foam compression set reference | 10% | |
| Expected service life in public space | 5 years | |
| Total seated capacity | 12 persons | |
| Distributed seat static load per single module | 150 kg | |
| Total unit weight (12-module X configuration) | 96 kg | |
| Foam compression set acceptance threshold | 10% | |
| Expected service life in medium-traffic public space | 5 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat top upholstery (purple) | Woven contract fabric with bi-color finish, stitched over foam padding | |
|---|---|---|
| Side body upholstery (yellow) | Woven contract fabric covering vertical and end panels | |
| Seat cushion fill | Polyurethane foam core of medium firmness inside a fabric sock | |
| Internal support frame | Plywood or particleboard internal box frame supporting foam and upholstery | |
| Bottom base panel | Black or non-visible structural base panel with floor glides | |
| Stitching and seams | Lockstitch seams joining fabric panels at module edges and color boundaries | |
| Module connectors | Hidden mechanical fasteners linking adjacent X-arm modules | |
| End cap stiffener | Injected polypropylene or plywood stiffener inside rounded end modules to retain curved shape | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Modular reconfiguration | Modules join into an X layout with four seating arms radiating from a central intersection | |
|---|---|---|
| Four-directional seating | Seating surfaces face outward on all four arms, allowing users to sit facing away from the center | |
| Backless bench use | No backrest; seat surface only, suitable for short-duration waiting and informal seating | |
| Upholstered impact absorption | Foam-cushioned seat provides a softer sitting surface than hard wood or metal benches | |
| Floor-protected placement | Bench rests on base glides to prevent floor scratching and dampen vibration | |
| Two-tone visual coding | Purple top and yellow side panels create strong visual identity and wayfinding cues in large public interiors | |
| Four-directional outward seating | Seating surfaces face outward on all four arms, allowing users to sit facing away from the central junction | |
| Backless short-duration seating | No backrest structure; flat seat surface only, suitable for 30-minute maximum casual waiting and informal seating | |
| Upholstered impact and pressure absorption | 120 mm polyurethane foam-cushioned seat provides a softer sitting surface than hard wood or metal benches | |
| Scratch-resistant floor placement | Bench rests on integrated base glides to prevent hard floor scratching and dampen minor vibration during use | |
| Two-tone visual wayfinding coding | Purple top and yellow side panels create high-contrast visual identity and wayfinding cues in large public interiors | |
| Tapered silhouette collision reduction | Bench body tapers from 400 mm seat width to 360 mm base width, reducing lower-leg collision risk in walking zones |
Verified carton / gross weight / assembly / loading data
| Packing method | Flat-packed per module with corner protection and foam wrap inside carton | |
|---|---|---|
| Single module carton dimensions | 820 x 420 x 470 mm | |
| Single module gross weight | 20 kg | |
| Single module CBM | 0.162 m³ | |
| Assembly time per X unit (12 modules) | 120 minutes | |
| 20 ft container loading quantity | 120 modules | |
| Single straight module carton dimensions | 820 x 420 x 470 mm | |
| Single straight module gross weight | 20 kg | |
| Single straight module cubic volume | 0.162 m³ | |
| X configuration assembly time (12 modules) | 120 minutes |
Recommended spaces / users / usage modes
| Airport and rail terminal waiting areas | Backless X layout serves high passenger throughput with multi-directional seating and clear sightlines | |
|---|---|---|
| Mall and retail atrium rest zones | Two-tone modular bench acts as both seating and visual landmark in large open interiors | |
| Corporate campus lobbies and break areas | Modular configuration accommodates informal meetings and individual short breaks | |
| Exhibition and trade show halls | Lightweight modular units can be reconfigured between events for visitor rest and brand-colored zones | |
| School and university common spaces | Durable upholstered form supports student study, group discussion, and waiting between classes | |
| Shopping mall and retail atrium rest zones | Two-tone modular bench acts as both seating and visual landmark in large open interiors | |
| Library and cultural center public areas | Low-backless design maintains clear sightlines for security while providing flexible seating for patrons | |
| Recommended Matching Desk Size | 2.4 m executive desk |
European market access and chemical requirements
| EN 1021-1 / EN 1021-2 | Applicable standards and test results require confirmation | |
|---|---|---|
| EN 12520 | Applicable standards and test results require confirmation | |
| EN 14322 | Recommended standard for safety and performance of contract seating used in public places; applicable for modular public bench acceptance testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Applicable as durability and safety reference for public and lounge seating in commercial interiors |
|---|
Standards applicable to China-market projects
| GB 20286-2006 | Recommended fire safety standard for upholstered furniture in public places; applicable to seating used in indoor public assembly areas | |
|---|---|---|
| GB/T 16799-2008 | Recommended standard for furniture upholstery leather and fabric physical and mechanical properties; applicable for wear resistance and seam strength acceptance |
This product must meet the following technical requirements: 1. GB 20286-2006: Recommended fire safety standard for upholstered furniture in public places; applicable to seating used in indoor public assembly areas; 2. GB/T 16799-2008: Recommended standard for furniture upholstery leather and fabric physical and mechanical properties; applicable for wear resistance and seam strength acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
Open Export ToolThe X-Shaped Modular Upholstered Public Bench (model BENCH-MOD-X-01) presents a striking, functional seating solution designed for high-traffic public and commercial spaces. Its visual form is defined by a bold X layout, with four seating arms radiating symmetrically from a central intersection module. The bench features a two-tone color scheme, with purple woven contract fabric covering the seat tops and bright yellow woven contract fabric wrapping the vertical side panels and rounded end caps. This high-contrast palette creates a strong visual identity that doubles as wayfinding cues in large open interiors. Each seating arm consists of repeating padded segments joined by narrow vertical lockstitch seams, while the rounded ends of each arm add soft, approachable edges. The bench body tapers from a wider seat top to a narrower base, giving it a light, streamlined silhouette that reduces lower-leg collision risk in walking zones. Constructed with an internal support frame of plywood or particleboard, the bench features a medium-firm polyurethane foam core seat cushion covered in durable woven contract fabric. The foam cushion provides impact and pressure absorption, delivering a softer sitting surface than hard wood or metal alternatives while remaining firm enough for high-traffic public use. Hidden mechanical fasteners link adjacent modules to form the X configuration, and stiffeners inside the rounded end modules retain their curved shape. The bench rests on base glides that protect floors from scratching and dampen minor vibration during use. This backless bench supports four-directional outward seating, allowing users to sit facing away from the center in any of the four directions. Its low-profile design maintains unobstructed sightlines, making it ideal for short-duration casual waiting of up to 30 minutes. The modular construction enables reconfiguration into multiple geometric layouts beyond the standard X shape, offering flexible seating density adjustments. The total seated capacity reaches 12 persons across the full X configuration, with each module supporting a distributed static load of 150 kg. The bench has an expected service life of 5 years under normal waiting-area use in medium-traffic public spaces. Suitable spaces include airport and rail terminal waiting areas, where its open form accommodates high passenger throughput and clear sightlines for circulation between gates. In mall and retail atrium rest zones, it serves as both functional seating and a visual landmark, with its color blocks supporting wayfinding for shoppers. It also works well in corporate campus lobbies and break areas, exhibition and trade show halls, school and university common spaces, and library and cultural center public areas, where its flexible layout and unobtrusive profile support both individual use and small-group informal gatherings. Procurement teams should note that exact fiber composition, abrasion ratings, foam density, frame material grades, and connector specifications require confirmation from the supplier’s bill of materials. Custom color options depend on the supplier’s minimum order quantity. The bench ships flat-packed per module, with corner protection and foam wrap inside cartons for transit. Full assembly of a 12-module X configuration takes 120 minutes on site, including unpacking, module alignment, and installation of hidden connectors. Freight planning can reference a single module gross weight of 20 kg and cubic volume of 0.162 m³, with 120 modules fitting in a 20 ft container.
