Automatic mm / inch conversion · Core engineering specifications
| Overall L-shape set footprint | 4200 x 2800 x 450 mm | |
|---|---|---|
| Seat height from finished floor | 450 mm | |
| Long linear bench unit width | 2970 mm | |
| Bench unit seating depth | 730 mm | |
| Square pouf ottoman dimensions | 600 x 600 x 450 mm | |
| Round cylindrical pouf diameter | 500 mm | |
| Central round side table diameter | 800 mm | |
| Central side table height | 500 mm | |
| Upholstered seat top thickness | 120 mm | |
| Small dark green bolster unit dimensions | 1000 x 450 x 400 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total seating capacity | 12 persons | |
|---|---|---|
| Per-seat static load rating | 260 kg | |
| Total set net weight reference | 280 kg | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Cushion foam density | 45 kg/m³ | |
| Cushion foam rebound rate | 60% | |
| Seam stitch pitch | 30 mm | |
| Limited commercial warranty | 3 years | |
| Available color configuration count | 2 | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat internal frame | 18mm thick plywood with reinforced corner blocking | |
|---|---|---|
| Seat upholstery | 280gsm commercial-grade woven polyester fabric, stain-resistant treatment | |
| Cushion core | High-density polyurethane foam, 120mm thickness, no sinuous spring base | |
| Unit support feet | 20mm tall black plastic glides with felt bottom to protect hard flooring | |
| Side table top | 25mm thick engineered wood with light oak veneer finish, rounded edges | |
| Side table legs | 12mm diameter powder-coated black steel hairpin legs with cross-brace | |
| Upholstery edge finishing | Sewn piped edges with rounded corners to prevent impact injury | |
| Under-seat support webbing | 50mm wide high-resilience polypropylene webbing, 80mm spacing | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
| Modular unit reconfiguration | Individual bench and pouf units connect via hidden underside hook brackets for custom layouts | |
|---|---|---|
| Surface maintenance | Fabric upholstery supports spot cleaning with mild upholstery detergent for public space upkeep | |
| Floor protection | All unit base glides are non-marking to prevent scratches on polished stone or tile flooring | |
| Flexible accessory placement | Pouf ottomans can be repositioned freely around central tables for ad-hoc seating groups | |
| Low-profile space division | Long L-shaped bench units create soft waiting zone boundaries without blocking sightlines in open lobbies | |
| Cushion performance retention | High-density foam core retains shape after 80000 cyclic compression loads for high-traffic use | |
| Installation requirement | All units are fully pre-upholstered, requiring only placement and connection of modular brackets on site | |
| Color customization | Upholstery colors can be specified for commercial orders to match interior design schemes | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Commercial office lobby waiting areas | Provides flexible, durable casual seating for visitors and guests in high-footfall public spaces | |
|---|---|---|
| Hotel reception lounge zones | Creates soft, approachable waiting areas with customizable color schemes to match interior design | |
| Hospital outpatient waiting areas | Offers easy-to-clean, high-capacity seating with rounded edges for user safety | |
| Corporate campus common areas | Supports casual collaboration and informal rest breaks for employees in open breakout spaces | |
| Bank and public service hall waiting zones | Delivers high load capacity and low maintenance requirements for constant daily public use | |
| Event venue pre-function spaces | Allows rapid reconfiguration of seating layouts to accommodate different event sizes and flows |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Furniture seating stability test standard, applicable to all standalone and connected bench units | |
|---|---|---|
| EN 13759:2003 | Upholstered seating durability test for cyclic loading, applicable to commercial high-traffic use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.41-2020 | Standard for lounge seating public area performance, covering static load and durability |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal plywood frame structural stability | |
|---|---|---|
| GB/T 16799-2008 | Performance requirements for furniture upholstery fabrics, applicable to abrasion and colorfastness testing | |
| GB 20286-2006 | Flame retardant requirements for upholstered furniture in public places, mandatory for public lobby applications |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal plywood frame structural stability; 2. GB/T 16799-2008: Performance requirements for furniture upholstery fabrics, applicable to abrasion and colorfastness testing; 3. GB 20286-2006: Flame retardant requirements for upholstered furniture in public places, mandatory for public lobby applications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
