Automatic mm / inch conversion · Core engineering specifications
| Finished Seat Cushion Thickness | 90 mm | |
|---|---|---|
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set static weight capacity | 300 kg | |
|---|---|---|
| Table top static load capacity | 50 kg | |
| Seat cushion density | 45 kg/m³ | |
| Backrest foam density | 35 kg/m³ | |
| Acoustic privacy rating | 25 dB | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg | |
| Caster Rolling Durability Reference | Acceptance target 30000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat upholstery | Polyester contract fabric with 50000-cycle Martindale abrasion resistance | |
|---|---|---|
| Seat core structure | 25 mm plywood inner frame wrapped in high-resilience polyurethane foam | |
| Backrest panels | Vertical fabric-wrapped foam panels with integrated side privacy wings | |
| Integrated lumbar pad | Curved soft foam cushion sewn to lower backrest | |
| Table top | 18 mm white solid laminate surface with matte finish | |
| Table column support | 80 mm diameter polished 304 stainless steel central tube | |
| Table base plates | 10 mm thick brushed stainless steel square flat bases | |
| Seat base glides | Non-marking polypropylene floor glides | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Acoustic privacy screening | Full-height upholstered back and side panels block peripheral distraction and reduce conversational sound travel | |
|---|---|---|
| Face-to-face collaborative layout | Two seats positioned opposite each other across the central table to support 2-person discussions or focused work | |
| Freestanding modular placement | Units require no floor or wall fixing, and can be repositioned or reconfigured as needed | |
| Upright work support | 105-degree angled backrest supports comfortable seated posture for laptop use or short meetings | |
| Floor protection | Low-profile glides under each seat prevent scuffing and allow gentle repositioning without lifting | |
| Table stability design | Dual stainless steel base plates prevent tipping when users lean on table edges | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions | 1300 x 950 x 1400 mm for seats, 1250 x 750 x 150 mm for table | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Open office focus zones | Creates semi-enclosed quiet spaces for individual focused work without full room construction | |
|---|---|---|
| Small collaborative meeting areas | Supports 2-person quick discussions, informal interviews or laptop-based co-working | |
| Corporate breakout spaces | Fits in staff lounge or breakout zones for casual work, coffee meetings or short calls | |
| Co-working space private nooks | Provides individual semi-private work spots for hot-desking environments | |
| Healthcare and public waiting areas | Offers separated, comfortable seating with reduced cross-conversation noise | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Office furniture structural strength | EN 16139:2013 | |
|---|---|---|
| Furniture surface resistance | EN 12720:2013 |
US and Canada office-furniture standards
| Lounge seating durability | ANSI/BIFMA X2022 | |
|---|---|---|
| Occasional table stability | ANSI/BIFMA X2021 |
Standards applicable to China-market projects
| Upholstered furniture flammability | GB 20286 | |
|---|---|---|
| Formaldehyde emission limits | GB 18580 |
This product must meet the following technical requirements: 1. Upholstered furniture flammability: GB 20286; 2. Formaldehyde emission limits: GB 18580; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
