Automatic mm / inch conversion · Core engineering specifications
| Overall unit dimensions | 1650 x 800 x 1473 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Seat depth | 762 mm | |
| Seat width per single unit | 780 mm | |
| Support leg height | 250 mm | |
| Back enclosure height above seat | 1023 mm | |
| Front entry opening width | 780 mm | |
| Seat cushion thickness | 120 mm | |
| Fabric panel thickness | 50 mm | |
| Matching side table height | 500 mm | |
| Support leg diameter | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Seat static load capacity | 150 kg | |
|---|---|---|
| Net weight per single booth | 80 kg | |
| Acoustic sound reduction | 15 dB | |
| Fabric abrasion rating | 100000 Martindale cycles | |
| Cushion foam density | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Frame static load rating | 200 kg | |
| Warranty period | 5 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer enclosure upholstery | Woven commercial polyester fabric | |
|---|---|---|
| Inner enclosure upholstery | Soft textured woven acoustic fabric | |
| Inner frame core | 18mm thick engineered wood panel | |
| Acoustic infill | High-density recycled polyester acoustic fiber | |
| Seat cushion padding | 45kg/m³ high-resilience polyurethane foam | |
| Support legs | 30mm wall thickness powder-coated steel cylinder | |
| Lumbar throw pillows | Fabric-wrapped polyester fiber fill cushions | |
| Underside floor glides | Non-marking nylon floor protection glides | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Access design | Open front entry with no door for unobstructed seating access | |
|---|---|---|
| Acoustic screening | Three-sided padded wrap provides partial speech privacy in open offices | |
| Seating configuration | Fixed integrated bench seat with no recline or adjustment mechanisms | |
| Elevation design | Unit raised on legs to allow floor cleaning access underneath | |
| Modular placement | Freestanding unit supports standalone or paired installation as shown | |
| Color customization | Two-tone exterior/interior fabric with optional custom colorways | |
| Accessory compatibility | Compatible with adjacent matching small round side tables | |
| Floor protection | Integrated non-marking glides prevent scuffing on hard office floors | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Open office collaboration zones | Semi-private nook for individual focused work or short 1:1 discussions | |
|---|---|---|
| Corporate breakout areas | Casual lounge seating for informal breaks or impromptu conversations | |
| Co-working space common areas | Distinct semi-enclosed seating to define personal space in shared layouts | |
| Educational campus lounges | Private study nook for students in open learning commons | |
| Reception waiting zones | Distinct seating option for visitors seeking partial privacy | |
| Library quiet areas | Individual reading nook with partial acoustic separation | |
| Startup office creative spaces | Playful house-shaped design supports casual creative work sessions | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Office furniture — Visitor seating performance requirements | |
|---|---|---|
| EN 1022:2018 | Domestic and contract seating — Stability test standard | |
| EN 16139:2013+A1:2021 | Strength and durability for non-domestic seating |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge seating performance and durability standard | |
|---|---|---|
| ANSI/BIFMA X7.1-2021 | Furniture emissions standard for low chemical emissions | |
| ANSI/BIFMA e3-2019e | Furniture sustainability standard for commercial products |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to inner frame | |
|---|---|---|
| GB/T 19001-2016 | Quality management systems guideline for contract furniture production | |
| GB 18580-2017 | Formaldehyde emission limits for engineered wood components | |
| GB/T 27904-2011 | Upholstered furniture flammability performance guideline |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to inner frame; 2. GB/T 19001-2016: Quality management systems guideline for contract furniture production; 3. GB 18580-2017: Formaldehyde emission limits for engineered wood components; 4. GB/T 27904-2011: Upholstered furniture flammability performance guideline; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
