Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (S-curve configuration) | 3200 x 3200 mm | |
|---|---|---|
| Seat height of curved sofa units | 420 mm | |
| Total height of lower curved backrest segment | 450 mm | |
| Total height of upper curved backrest segment | 800 mm | |
| Seat depth of curved sofa units | 600 mm | |
| Round central side table dimensions | 600 x 450 mm | |
| Small round side table (red ottoman adjacent) dimensions | 500 x 500 mm | |
| Cylindrical ottoman (green, blue) dimensions | 350 x 400 mm | |
| Hexagonal ottoman (red, dark gray) dimensions | 350 x 420 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest panel thickness | 80 mm | |
| Solid wood table leg diameter | 40 mm | |
| Lower curved backrest segment total height | 450 mm | |
| Upper curved backrest segment total height | 800 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm |
Net weight / load capacity / users / durability
| Total set net weight | 215 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Total seating capacity in standard S-configuration | 8 persons | |
| Cushion foam density | 35 kg/m³ | |
| Cushion foam rebound rate | 45% | |
| Upholstery fabric abrasion resistance (Martindale) | 30000 cycles | |
| Product warranty period | 3 years | |
| Seat cushion foam density | 35 kg/m³ | |
| Seat cushion foam rebound rate | 45% | |
| Upholstery fabric Martindale abrasion resistance | 30000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat cushion upholstery | Two-tone blue woven polyester fabric | |
|---|---|---|
| Backrest panel upholstery | White woven polyester fabric | |
| Ottoman upholstery | Polyester fabric in four finish colors (green, dark blue, red, dark gray) | |
| Inner structural frame | 15mm thick multi-layer engineered plywood frame | |
| Seat cushion core | High-resilience polyurethane foam with 10mm soft top layer | |
| Backrest core | Medium-density polyurethane foam over hardboard backing | |
| Side tabletops | 18mm thick white matte laminated MDF panel | |
| Side table legs | Solid natural beech wood with clear matte lacquer finish | |
| Unit base glides | Black non-marking nylon floor glides | |
| Upholstery stitching | Reinforced polyester thread with 30mm seam pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Modular section connection | Hidden sliding metal connectors link adjacent curved seat units to maintain S-curve alignment | |
|---|---|---|
| Layout flexibility | Individual curved and ottoman units can be repositioned to form circular, serpentine or linear seating layouts | |
| Table integration | Two round side tables are sized to fit within the inner curve of seating loops to hold refreshments, reading materials or decorative items | |
| Movable ottoman use | Four lightweight upholstered ottomans can be used as supplemental seating, footrests or moved to adjacent spaces as needed | |
| Backrest support design | Dual-height backrests provide upper and lower back support for users seated on corresponding curved segments | |
| Floor protection | Non-marking nylon glides prevent scuffing to hard floor surfaces and allow gentle repositioning of units without lifting | |
| Upholstery maintenance | Removable upholstery covers with hidden zippers allow spot cleaning or replacement | |
| Layout reconfiguration | Individual curved seat, backrest and ottoman units can be rearranged to form circular, serpentine or linear seating layouts, no permanent floor mounting required | |
| Integrated table placement | Two round side tables fit within the inner curve of seating loops to hold refreshments, reading materials or personal items during seated use | |
| Movable ottoman utility | Four lightweight upholstered ottomans function as supplemental seating, footrests or can be relocated to adjacent spaces as needed | |
| Dual-height back support | Two-tier curved backrests provide targeted lumbar support for lower seats and upper back support for taller seating segments, following the continuous S-curve profile | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions |
Verified carton / gross weight / assembly / loading data
| Total shipping carton count | 10 cartons | |
|---|---|---|
| Largest carton dimensions (curved seat unit) | 1600 x 800 x 450 mm | |
| Total shipment gross weight | 245 kg | |
| Total shipment volume | 2.3 CBM | |
| On-site assembly time | 90 minutes | |
| 40ft HQ container loading quantity (full sets) | 28 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set |
Recommended spaces / users / usage modes
| Office public waiting areas | Suitable for lobby and reception zones in corporate offices, providing informal grouped seating for visitors and waiting staff | |
|---|---|---|
| Educational institution common spaces | Suitable for student lounges, library break areas and campus collaboration spaces, supporting both individual relaxation and small group discussion | |
| Public service hall waiting areas | Suitable for government service centers, bank lobbies and hospital outpatient waiting zones, offering high capacity durable seating for high foot traffic locations | |
| Creative studio break spaces | Suitable for design studios, co-working spaces and media company relaxation areas, with bright multicolor finish matching modern casual workspace aesthetics | |
| Retail and exhibition spaces | Suitable for mall rest zones, exhibition booth rest areas and product launch event seating, creating visually distinctive organized seating areas for attendees | |
| Corporate office reception areas | Suitable for lobby and visitor waiting zones in corporate offices, creating natural conversation groups for waiting guests and staff | |
| Co-working and creative studio break spaces | Suitable for design studios, flexible office spaces and media company relaxation areas, with multi-color upholstery matching modern casual workspace aesthetics | |
| Retail and exhibition rest zones | Suitable for shopping mall rest areas, exhibition booth seating and product launch event attendee areas, creating visually distinctive organized seating zones |
EU Market Access Requirements* EN Standards
| EN 13759:2012 Furniture - Seating - Test methods for the determination of strength and durability | Applicable for cyclic load and structural durability validation of all seating units for commercial use | |
|---|---|---|
| EN 1021-1:2014 Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette | Applicable for basic fire safety testing of upholstered seat and back components | |
| EN 16139:2013 Furniture - Strength, durability and safety - Requirements for non-domestic seating | Applicable for performance validation for public and office lounge space use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 Lounge and Public Seating | Applicable for static load, stability and durability testing for commercial public lounge applications |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for furniture | Applicable for structural safety, dimensional tolerance and finish quality inspection of wooden and upholstered furniture units in this set | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable for formaldehyde emission testing of all engineered wood and laminate components | |
| GB/T 1952.1-2012 Upholstered furniture - Sofas | Applicable for seating durability, cushion performance and structural stability testing of sofa units |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for furniture: Applicable for structural safety, dimensional tolerance and finish quality inspection of wooden and upholstered furniture units in this set; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable for formaldehyde emission testing of all engineered wood and laminate components; 3. GB/T 1952.1-2012 Upholstered furniture - Sofas: Applicable for seating durability, cushion performance and structural stability testing of sofa units; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
