Wood-Grain Executive Desk with Left Storage Pedestal and Open Bookcase (model EDK-WN1800-4D-BC24) is listed under Executive Office Desk for Boss/Executive. Dimensions: 1800 × 900 × 750 mm. Materials: 25 mm E1-class wood-composite substrate with 38 mm visible build-up, walnut-tone melamine face and 2 mm PVC edge banding. Load capacity: 80 kg. Product Features: Walnut-tone,finish,Dark,gray,storage,Steel-leg,frame,Fixed-height,desk,Left,pedestal,Open,shelving. This page consolidates 6 groups of specifications and ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | GENUOWA | Model | EDK-WN1800-4D-BC24 |
| Finished Top Thickness | 50 mm | Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
| Desk static top load | 80 kg | Pedestal drawer load per drawer | 15 kg |
| Bookcase shelf load | 25 kg per shelf | Recommended user size range | 1900 mm body height |
| Seating capacity | 1 working occupant plus 2 visitor seats | Drawer slide cycle rating | 50000 open-close cycles |
| Net desk and cabinet weight | 128 kg | Wall bookcase overturn resistance | 45 kg lateral restraint force |
| Top Static Load Reference | 150 kg uniformly distributed | Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
| Desktop substrate and finish | 25 mm E1-class wood-composite substrate with 38 mm visible build-up, walnut-tone melamine face and 2 mm PVC edge banding | Pedestal panels | 18 mm dark graphite melamine-faced composite board with walnut-tone drawer recesses |
| Bookcase exterior | 18 mm walnut-tone melamine composite side panels and dividers with matching edge banding | Bookcase interior and back | 18 mm black melamine composite shelves with 8 mm black back panel |
| Support frame | 50 x 50 mm powder-coated square steel tube legs with welded underside rails | Drawer hardware | Three-section side-mounted ball-bearing slides with recessed horizontal pulls and integrated drawer stops |
| Fixed-height work surface | Provides a 750 mm seated writing and laptop surface with four steel support points; no height-adjustment mechanism is visible | Left pedestal storage | Four vertically stacked drawers supply stationery and file storage, with an expected 420 mm full-extension drawer travel |
| Cable management | Rear modesty panel conceals the user-facing knee zone and supports a 60 mm grommet-cap routing path for laptop power and data cables | Leveling and installation | Four threaded leveling feet compensate up to 12 mm on uneven carpet or hard floors before the desk is loaded |
| Packed carton count | 4 cartons | Reference Package Count | 1 set / 2 cartons |
| Reference Assembly Time | 40 minutes per set | Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | Reference Packaging Volume | 1 m³/set |
| Executive or manager office | Suits a private office requiring a 1800 mm work surface, four-drawer pedestal and coordinated tall storage for files and display items | Professional meeting and visitor layout | The open front face supports laptop-based discussions with one or two visitors seated across the desk |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desk static top load | 80 kg | |
|---|---|---|
| Pedestal drawer load per drawer | 15 kg | |
| Bookcase shelf load | 25 kg per shelf | |
| Recommended user size range | 1900 mm body height | |
| Seating capacity | 1 working occupant plus 2 visitor seats | |
| Drawer slide cycle rating | 50000 open-close cycles | |
| Net desk and cabinet weight | 128 kg | |
| Wall bookcase overturn resistance | 45 kg lateral restraint force | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate and finish | 25 mm E1-class wood-composite substrate with 38 mm visible build-up, walnut-tone melamine face and 2 mm PVC edge banding | |
|---|---|---|
| Pedestal panels | 18 mm dark graphite melamine-faced composite board with walnut-tone drawer recesses | |
| Bookcase exterior | 18 mm walnut-tone melamine composite side panels and dividers with matching edge banding | |
| Bookcase interior and back | 18 mm black melamine composite shelves with 8 mm black back panel | |
| Support frame | 50 x 50 mm powder-coated square steel tube legs with welded underside rails | |
| Drawer hardware | Three-section side-mounted ball-bearing slides with recessed horizontal pulls and integrated drawer stops |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Fixed-height work surface | Provides a 750 mm seated writing and laptop surface with four steel support points; no height-adjustment mechanism is visible | |
|---|---|---|
| Left pedestal storage | Four vertically stacked drawers supply stationery and file storage, with an expected 420 mm full-extension drawer travel | |
| Cable management | Rear modesty panel conceals the user-facing knee zone and supports a 60 mm grommet-cap routing path for laptop power and data cables | |
| Leveling and installation | Four threaded leveling feet compensate up to 12 mm on uneven carpet or hard floors before the desk is loaded |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Packed carton count | 4 cartons | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive or manager office | Suits a private office requiring a 1800 mm work surface, four-drawer pedestal and coordinated tall storage for files and display items | |
|---|---|---|
| Professional meeting and visitor layout | The open front face supports laptop-based discussions with one or two visitors seated across the desk |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
