Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 2000 x 750 mm | |
|---|---|---|
| Main worktop thickness | 50 mm | |
| Return worktop depth | 600 mm | |
| Seated knee clearance height | 660 mm | |
| Seated knee clearance width | 1600 mm | |
| Storage pedestal width | 800 mm | |
| Fluted modesty panel height | 500 mm | |
| Right vertical support leg width | 80 mm | |
| Desk base plinth height | 40 mm | |
| Embedded cable grommet diameter | 80 mm | |
| Ventilation slot length on pedestal side | 120 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight range | 185 kg | |
|---|---|---|
| Worktop static uniform load capacity | 150 kg | |
| Pedestal drawer static load per drawer | 45 kg | |
| Recommended maximum user weight for seating use | 150 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Design service life under daily office use | 10 years | |
| Leveling adjustment range for feet | 10 mm | |
| Recommended maximum seated user weight | 150 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating (if fitted) | 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop surface | Walnut-toned wood veneer over 25mm thick MDF substrate with 25mm matching edge build-up, matte PU lacquer finish | |
|---|---|---|
| Storage pedestal outer panels | Matching wood veneer over 18mm MDF substrate, matte lacquer finish with polished beveled edge detailing | |
| Knee bay modesty panels | Medium grey matte lacquered MDF with vertical fluted grooved texture | |
| Structural support frame | 2mm thick powder-coated cold-rolled steel with dark grey matte finish, forming internal worktop support, right leg structure and base plinth | |
| Accent trim detail | 0.8mm thick brushed gold-toned stainless steel inlay, set vertically along right support leg edge | |
| Pedestal internal drawer components | 15mm thick particleboard drawer boxes with full-extension cold-rolled steel drawer slides | |
| Leveling feet | Nylon base with steel threaded stem, installed at all base contact points | |
| Cable grommet | Brushed ABS plastic with removable brush insert, fitted flush to worktop surface | |
| Under-desk cable tray | 0.9mm thick powder-coated cold-rolled steel, mounted under rear worktop to contain routed cables | |
| Drawer soft-close dampers | Thermoplastic damper units integrated into slide mechanisms, providing controlled silent closure | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Left fixed pedestal provides enclosed storage with 2 box drawers for supplies and 1 lateral file drawer for A4/letter size hanging files, plus dedicated vented CPU compartment with horizontal side ventilation slots | |
|---|---|---|
| Cable management system | Rear worktop embedded grommet routes power and data cables to under-desk space, with hidden under-top cable tray to contain wiring and maintain clean appearance | |
| Privacy screening | Full-height fluted modesty panel spans entire open knee bay, blocking view of under-desk area and user legs from front office sightlines | |
| Stability and leveling | Threaded adjustable glides at all base contact points allow up to 10mm height adjustment to level the desk on uneven carpet or hard flooring without wobble | |
| Work surface layout | L-shaped configuration provides dual work zones: main forward work area for monitor and writing tasks, and side return area for peripherals, document review or guest interaction | |
| Drawer operation | Full-extension soft-close drawer slides allow drawers to open fully for complete access to stored contents, with dampened closure to prevent slamming and reduce office noise | |
| CPU compartment ventilation | Five 120mm long horizontal vent slots on the pedestal side panel provide passive cross-ventilation for stored tower CPUs, preventing overheating during 8+ hours daily operation | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 3 | |
|---|---|---|
| Largest carton dimensions | 2450 x 950 x 120 mm | |
| Total shipping gross weight | 210 kg | |
| Total shipping volume (CBM) | 0.82 | |
| On-site assembly time | 120 minutes | |
| Assembly hardware kit contents | All required bolts, screws, hex key, adjustable glides and cable grommet components included in dedicated hardware pack | |
| 40ft HQ container loading quantity | 52 units | |
| Recommended factory warranty | 5 years | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Executive private office space | Suitable for senior management and executive private offices, provides expansive work surface and integrated storage to support administrative, meeting and focused work tasks | |
|---|---|---|
| Managerial open office workstation | Suitable for senior team member workstations in open plan offices, provides private storage and front modesty panel screening without requiring full height office partitions | |
| Conference room leader station | Suitable for head-of-table placement in small boardrooms or meeting rooms, provides work surface for meeting materials and integrated cable access for presentation equipment | |
| Professional reception manager workspace | Suitable for reception area manager positions, provides storage for administrative supplies and a polished appearance consistent with client-facing office spaces | |
| Recommended pairing | Pairs with high-back executive leather office chairs with 700mm diameter five-star base, as the 660mm knee clearance accommodates full seat height and tilt adjustment without contact | |
| Recommended seating pairing | Pairs with high-back executive leather office chairs with 700mm diameter five-star base and 120kg weight rating, as the 660mm knee clearance accommodates full 580 mm seat height adjustment and 15° back tilt without contact | |
| Home executive office setup | Suitable for dedicated high-end home offices for remote senior professionals, provides commercial-grade durability and integrated cable management to support multi-monitor home workstations with clean visual appearance |
EU Market Access Requirements* EN Standards
| Office desk safety recommendation | EN 527:2011 Office furniture - Work tables and desks - Part 1: Dimensions | |
|---|---|---|
| Structural durability recommendation | EN 527:2002 Office furniture - Work tables and desks - Part 2: Mechanical safety requirements and test methods | |
| Surface performance recommendation | EN 15185:2011 Furniture - Assessment of surface resistance to abrasion | |
| Hardware performance recommendation | EN 15338:2007 Furniture hardware - Drawer slides and sliding components - Requirements and test methods |
US and Canada office-furniture standards
| Desk performance recommendation | ANSI/BIFMA X2021Desk Products - Tests for safety, durability and structural adequacy | |
|---|---|---|
| Sustainability recommendation | ANSI/BIFMA e2019Furniture Sustainability Standard |
Standards applicable to China-market projects
| Desk structural safety recommendation | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Surface emission recommendation | GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | |
| Hardware durability recommendation | GB/T 10357.1Test of mechanical properties of furniture - Strength and durability of tables | |
| Surface finish recommendation | GB/T 4893.8Test of surface coatings for furniture - Part 8: Determination of abrasion resistance |
This product must meet the following technical requirements: 1. Desk structural safety recommendation: GB/T 3324General technical requirements for wooden furniture; 2. Surface emission recommendation: GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture; 3. Hardware durability recommendation: GB/T 10357.1Test of mechanical properties of furniture - Strength and durability of tables; 4. Surface finish recommendation: GB/T 4893.8Test of surface coatings for furniture - Part 8: Determination of abrasion resistance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
