Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| tabletop thickness | 38 mm | |
| central cable slot length | 600 mm | |
| central cable slot width | 80 mm | |
| under-table knee clearance height | 680 mm | |
| trestle leg spread (per side) | 800 mm | |
| leg beam cross-section width | 80 mm | |
| table corner radius | 30 mm | |
| leg setback from table end | 300 mm | |
| table edge bevel width | 10 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| net weight | 95 kg | |
|---|---|---|
| uniform tabletop static load capacity | 300 kg | |
| seating capacity | 8 people | |
| surface abrasion resistance | 2000 cycles | |
| surface stain resistance rating | Grade 4 | |
| leg assembly static stability load | 450 kg | |
| warranty period | 5 years | |
| available finish options | 6 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop core | 38mm thick high-density particleboard core | |
|---|---|---|
| tabletop surface | Light oak wood grain melamine laminate | |
| table edge banding | 2mm thick matching PVC edge banding | |
| support legs | 2mm thick powder-coated light gray steel tubing | |
| cable slot frame | Brushed aluminum alloy trim | |
| leg foot pads | 10mm thick non-slip TPE adjustable feet | |
| structural cross bracing | 1.5mm thick steel connecting brackets | |
| cable trough liner | ABS plastic wire management channel | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| central cable access | Recessed horizontal slot accepts power/HDMI/network modules | |
|---|---|---|
| adjustable foot leveling | 15mm vertical adjustment range on each foot | |
| full under-table clearance | Open unobstructed leg space along full table length | |
| tabletop surface function | Stain-resistant non-porous surface | |
| modular cable configuration | Slot supports custom power/data module fit-out | |
| knock-down assembly | Two-piece leg set attaches to pre-drilled tabletop | |
| floor protection | Soft TPE foot pads prevent hard floor scratches | |
| edge safety design | Rounded beveled edges reduce impact injury risk | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| corporate meeting rooms | Suited for 8-person team discussions, video conferences, and presentations | |
|---|---|---|
| training rooms | Supports laptop use, document review, and group training activities | |
| open office collaborative zones | Provides dedicated group work surface for cross-functional teams | |
| co-working spaces | Serves bookable shared meeting space for members | |
| educational facilities | Accommodates seminar sessions, group projects, and faculty meetings | |
| hotel business centers | Fits guest meeting and small event requirements |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables - Safety, strength and durability requirements | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for the assessment of surface resistance to dry heat |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office Furnishings - Desk Products - Tests | |
|---|---|---|
| ANSI/BIFMA M7.1-2020 | Standard Test Method for Measuring VOC Emissions |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 3327-2017 | Performance test for wooden office furniture tables | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 3327-2017: Performance test for wooden office furniture tables; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
