Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 4800 × 1600 × 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 380 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 480 kg | |
| Recommended maximum occupancy | 10 people | |
| Tabletop surface abrasion resistance | 2000 cycles | |
| Base static load rating | 960 kg | |
| Design service life | 10 years | |
| Seating capacity per long side | 4 positions | |
| Seating capacity per short end | 1 position | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 25mm high-density MDF core | |
|---|---|---|
| Tabletop surface finish | Matte wood veneer with anti-scratch lacquer | |
| Table edge banding | Matching solid wood veneer | |
| Vertical base panels | 36mm low-emission particleboard with matte dark gray lacquer | |
| Base accent strips | Walnut tone wood veneer inlays | |
| Support edge trim | Brushed 304 stainless steel | |
| Central cable channel cover | Brushed metal flip-top panel | |
| Leveling feet | Nylon-tipped adjustable steel glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Central cable management channel | Full-length recessed channel with removable cover to route power and data cables | |
|---|---|---|
| Integrated cable access points | Pop-up access ports positioned every 800mm along central channel for device connectivity | |
| Floor leveling adjustment | 15mm vertical adjustment range on base glides to compensate for uneven carpet or hard flooring | |
| Seating compatibility | Accommodates executive office chairs with 650mm maximum arm width between base supports | |
| Surface maintenance | Stain-resistant lacquer finish allowing wipe-clean disinfection without surface damage | |
| Modular assembly | Three-section tabletop joined with steel connector brackets for on-site assembly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive boardrooms | Sized for 10-person meetings in corporate headquarters and premium office spaces | |
|---|---|---|
| High-level client meeting rooms | Premium finish and formal scale suitable for executive client presentations | |
| Corporate training rooms | Large flat surface supports documents, laptops and presentation materials for group sessions | |
| Government conference facilities | Formal, low-profile aesthetic matches official meeting space design requirements | |
| Recommended pairing | Matches high-back leather executive conference chairs with chrome bases for unified styling |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office furniture strength requirement | EN 527:2003 | |
|---|---|---|
| Office furniture surface durability | EN 15187:2006 | |
| Office furniture stability | EN 14073:2004 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Conference table load test | ANSI/BIFMA X2021 | |
|---|---|---|
| Conference table stability | ANSI/BIFMA X2021 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Tabletop dimensional tolerance | GB/T 3324 | |
|---|---|---|
| Formaldehyde emission limit | GB 18580 | |
| Surface coating safety | GB 18584 |
This product must meet the following technical requirements: 1. Tabletop dimensional tolerance: GB/T 3324; 2. Formaldehyde emission limit: GB 18580; 3. Surface coating safety: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
