Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3000 x 1200 x 760 mm | |
|---|---|---|
| Tabletop thickness | 36 mm | |
| Edge band thickness | 2 mm | |
| Perimeter knee clearance height | 580 mm | |
| Cable grommet dimensions | 200 x 80 mm | |
| Outer metal leg tube diameter | 50 mm | |
| Central pedestal footprint | 800 x 400 mm | |
| Adjustable foot pad diameter | 40 mm | |
| Side panel overhang from leg | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Product net weight | 100 kg | |
|---|---|---|
| Uniform distributed static tabletop load | 300 kg | |
| Seating capacity | 10 people | |
| Recommended warranty period | 18 months | |
| Surface scratch resistance rating | 2000 cycles | |
| Substrate formaldehyde emission limit | 0.05 mg/m³ | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | High-density particleboard core | |
|---|---|---|
| Tabletop finish | Scratch-resistant melamine laminate | |
| Edge trim | 2 mm thick PVC edge banding | |
| Central support pedestal | 1.5 mm thick powder-coated steel | |
| Outer support legs | 1.5 mm thick steel tube legs | |
| Connecting frame | Powder-coated steel cross bracing | |
| Foot pads | Nylon adjustable anti-slip pads | |
| Cable grommets | ABS plastic rectangular cable ports | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Cable management access | Two recessed rectangular grommets with removable covers | |
|---|---|---|
| Surface leveling | Adjustable nylon foot pads on each leg | |
| Under-table clearance | Open knee space around full table perimeter | |
| Surface maintenance | Stain-resistant smooth laminate finish | |
| Modular assembly | Knock-down flat-pack construction | |
| Stability design | Central pedestal plus four corner leg layout | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | 10-person capacity for formal executive meetings and team decision sessions | |
|---|---|---|
| Open-plan office meeting zones | Two-tone modern finish fits contemporary open office design schemes | |
| Training and seminar spaces | Durable laminate surface supports frequent use for group training sessions | |
| Government conference facilities | E1 grade substrate and heavy-duty build meet public procurement durability standards | |
| Hybrid meeting rooms | Integrated cable grommets support AV and video conferencing equipment cabling | |
| Small business meeting spaces | Neutral colorway coordinates with standard office seating and storage furniture |
EU Market Access Requirements* EN Standards
| Office furniture safety | EN 527:2011 | |
|---|---|---|
| Formaldehyde emission | EN 13986:2004+A1:2015 | |
| Surface durability | EN 15185:2011 |
US and Canada office-furniture standards
| Table load performance | ANSI/BIFMA X2021 | |
|---|---|---|
| Stability testing | ANSI/BIFMA X2021 |
Standards applicable to China-market projects
| Table substrate emission | GB/T 39600 | |
|---|---|---|
| Office table dimensional stability | GB/T 3324 | |
| Metal coating durability | GB/T 2020 |
This product must meet the following technical requirements: 1. Table substrate emission: GB/T 39600; 2. Office table dimensional stability: GB/T 3324; 3. Metal coating durability: GB/T 2020; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
