Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 420 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity (closed) | 50 kg | |
|---|---|---|
| Internal storage compartment volume | 180 L | |
| Recommended maximum user weight on lifted top | 10 kg | |
| Lift mechanism cycle life | 10000 operations | |
| Product net weight | 48 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 18mm thick MDF core | |
|---|---|---|
| Tabletop surface | Walnut wood veneer with matte clear lacquer | |
| Base outer panels | Light gray matte lacquered MDF | |
| Base front panel | Vertically fluted light gray MDF | |
| Lift mechanism hardware | Powder-coated cold-rolled steel | |
| Recessed tabletop handle | Brushed stainless steel trim with black plastic insert | |
| Base foot pads | Non-slip PE plastic pads at four corners | |
| Storage compartment interior | Smooth melamine-lined MDF | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Lift-top operation | Spring-assisted hinge mechanism lifts and locks at full raised height | |
|---|---|---|
| Internal hidden storage | Enclosed compartment under tabletop for blankets, remotes and media accessories | |
| Dual-height use mode | Functions as standard coffee table at closed height, and work/dining surface when lifted | |
| Soft-close lowering | Dampened hinges prevent slamming when returning tabletop to closed position | |
| Integrated cable pass-through | Recessed center handle doubles as cable routing slot for charging devices | |
| Floor protection | Fixed non-marking foot pads prevent scuffing on hard flooring | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living rooms | Placed in front of sofas for drinks, decor and media storage, matches modern light neutral interiors | |
|---|---|---|
| Small apartment multi-use spaces | Lifted top provides work/dining surface without requiring a separate desk or dining table | |
| Executive lounge waiting areas | Suitable for modern office lounge spaces to hold reading materials and refreshments for guests | |
| Home media rooms | Hidden interior storage organizes remotes, cables and media accessories out of sight | |
| Open-plan studio apartments | Low-profile design avoids visual clutter while providing dual function as work surface and table |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic tables, applicable for performance verification | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for the assessment of surface resistance to cold liquids |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety verification | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety verification; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
