Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 4200 x 1400 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight | 185 kg | |
|---|---|---|
| Uniform distributed tabletop load | 240 kg | |
| Maximum seating capacity | 10 people | |
| Surface vertical impact resistance | 45 N | |
| Surface abrasion resistance | 2000 cycles | |
| Leg static load rating per pair | 320 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | High density particleboard core | |
|---|---|---|
| Tabletop finish | Matte white anti-scratch laminate | |
| Support leg frame | Powder-coated white carbon steel tube | |
| Leg decorative accent | Walnut wood veneer trim | |
| Leveling feet | Nylon adjustable floor glides | |
| Cable grommet trim | Matte ABS plastic | |
| Edge banding | 2mm thick PVC edge matching tabletop color | |
| Structural cross beam | Rectangular steel cross support under tabletop | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated cable management | Center tabletop grommet routes power/data cables to floor | |
|---|---|---|
| Floor leveling adjustment | Glides adjust 10mm vertically to compensate for uneven floors | |
| Seating accessibility | No middle cross braces to block legroom along full table length | |
| Surface maintenance | Matte laminate finish resists common office stains and wipe-clean | |
| Multi-device placement | Flat stable surface supports laptops, monitors and conference materials | |
| Modular assembly | Table breaks into top and leg assemblies for transport and installation | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Corporate conference rooms | Fits medium meeting spaces for 10-person team discussions | |
|---|---|---|
| Board meeting spaces | Minimalist professional finish matches modern executive office interiors | |
| Training rooms | Large flat surface supports training materials and laptops for all attendees | |
| Collaboration zones | Open under-table space allows flexible chair arrangement for group work | |
| Client meeting areas | Durable matte finish maintains appearance with regular daily use |
EU Market Access Requirements* EN Standards
| Office table safety and strength | EN 527:2002 | |
|---|---|---|
| Surface scratch resistance | EN 14323:2017 |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| Tabletop formaldehyde emission | GB/T 17657E0 ≤0.05mg/m³ | |
|---|---|---|
| Furniture structural stability | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Tabletop formaldehyde emission: GB/T 17657E0 ≤0.05mg/m³; 2. Furniture structural stability: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
