Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1200 × 750 mm | |
|---|---|---|
| Tabletop thickness | 36 mm | |
| Dark accent panel width | 600 mm | |
| Knee clearance height under table | 680 mm | |
| Knee clearance depth under table | 900 mm | |
| Cable grommet cutout size | 100 x 200 mm | |
| Left pedestal width | 500 mm | |
| Right pedestal width | 300 mm | |
| Base support panel thickness | 36 mm | |
| Overhang from pedestal edge to table end | 200 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Evenly distributed static tabletop load capacity | 113 kg | |
|---|---|---|
| Recommended seating capacity | 8 users | |
| Product net weight | 115 kg | |
| Surface scratch resistance rating | 2000 abrasion cycles | |
| Leveling foot adjustment range | 10 mm | |
| Warranty period | 5 years | |
| Available color finish options | 2 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Walnut main tabletop surface | Thermally fused melamine laminate over high-density MDF core | |
|---|---|---|
| Charcoal accent tabletop surface | Matte thermally fused melamine laminate over MDF core | |
| Tabletop edges | 2mm thick impact-resistant PVC edge banding | |
| Block pedestal base panels | Matte charcoal melamine laminated MDF panels | |
| Cable management grommet | ABS plastic flip-top cover with internal cable routing channel | |
| Base leveling feet | Reinforced polypropylene with metal threaded inserts | |
| Internal connecting hardware | Zinc-plated steel cam locks and confirmation screws | |
| Base support core | 36mm thick high-density particleboard with laminate facing | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Recessed grommet on left accent panel routes power/data cables from floor to tabletop | |
|---|---|---|
| Leveling adjustment | Threaded feet at each pedestal base adjust 10mm to stabilize on uneven floors | |
| Knock-down assembly | Flat-pack design assembles with included hex wrench and hardware for on-site installation | |
| Seating configuration | Supports 3 users per long side and 1 user per short end for 8-person meetings | |
| Surface maintenance | Non-porous laminate surface resists stains and wipes clean with standard office disinfectants | |
| Cable channel routing | Concealed channel behind front base panel hides cords from floor to grommet | |
| Load distribution | Dual pedestal supports spread weight evenly to prevent tabletop sag under 113kg load | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate boardrooms | Fits 8-person meeting spaces for executive meetings and client presentations | |
|---|---|---|
| Small office meeting rooms | Works in team collaboration spaces for internal staff meetings and training sessions | |
| Open office touchdown zones | Serves as a large collaborative work surface for group project work and video calls | |
| Co-working space meeting areas | Durable commercial finish withstands high-traffic shared use by multiple members | |
| Formal reception meeting spaces | Two-tone modern design presents a professional appearance for guest meetings |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2016 | Office work tables safety and strength requirements, applies to structural stability | |
|---|---|---|
| EN 14372:2004 | Furniture hardware strength requirements for connecting fasteners | |
| EN 13722:2004 | Surface resistance to abrasion and stains for laminated furniture surfaces |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 Clause 5 | Vertical static load test of 113kg applied to tabletop center for structural integrity |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to tabletop flatness and edge quality | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applies to structural panel core material performance | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to tabletop flatness and edge quality; 2. GB/T 4897.3-2015: Particleboard for furniture use, applies to structural panel core material performance; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
