Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 3000 x 1200 x 750 mm | |
|---|---|---|
| tabletop thickness | 30 mm | |
| under-table knee clearance height | 690 mm | |
| leg section outer diameter | 60 mm | |
| leg wall thickness | 2 mm | |
| integrated cable grommet length | 400 mm | |
| beveled edge width | 10 mm | |
| leg splay offset from table corner | 150 mm | |
| seating space per person | 700 mm | |
| floor glide adjustment height | 10 mm | |
| tabletop overhang past leg line | 80 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| distributed static tabletop load capacity | 450 kg | |
|---|---|---|
| product net weight | 60 kg | |
| surface abrasion resistance | 2000 cycles | |
| seating capacity | 8 persons | |
| leveling adjustment load per leg | 120 kg | |
| surface stain resistance rating | Grade 4 | |
| warranty period | 36 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop substrate | 28mm high-density particleboard core | |
|---|---|---|
| tabletop surface finish | Walnut wood grain melamine veneer, 0.6mm wear layer | |
| leg material | Powder-coated white cold-rolled steel | |
| support frame | Rectangular steel cross-bracing under tabletop | |
| cable grommet cover | Matte black ABS plastic | |
| floor glides | Nylon base with adjustable steel threaded insert | |
| connecting hardware | Zinc-plated steel bolts and cam locks | |
| edge banding | Matching walnut PVC beveled edge trim | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| cable management | Centered linear grommet routes power/data cables to under-table channels | |
|---|---|---|
| floor leveling | Threaded nylon glides adjust up to 10mm to correct uneven floors | |
| knock-down assembly | Tabletop and legs ship disassembled for flat-pack transport | |
| multi-person collaboration | 3000mm length supports 4 users per long side for group meetings | |
| surface protection | Scratch and stain resistant melamine finish withstands daily office use | |
| power module compatibility | 400mm grommet cutout accepts standard AC/USB/HDMI conference modules | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| corporate boardrooms | Seats 8 people for formal executive meetings and presentations | |
|---|---|---|
| open-plan collaboration areas | Supports team workshops, laptop-based group work and video calls | |
| co-working meeting spaces | Durable commercial finish withstands high daily use by rotating members | |
| training rooms | Stable surface supports notebooks, laptops and training materials for group sessions |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for structural performance validation | |
|---|---|---|
| EN 15372:2016 | Office furniture durability and safety requirements for non-domestic tables | |
| EN 13722:2004 | Furniture surface resistance to cold liquids, applicable for stain resistance validation |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for structural load and durability performance validation | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable for material emission testing reference |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for tabletop structural integrity | |
|---|---|---|
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable for tabletop wear validation | |
| GB/T 10357.1-1989 | Furniture mechanical performance test for tables, applicable for static load validation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for tabletop structural integrity; 2. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable for tabletop wear validation; 3. GB/T 10357.1-1989: Furniture mechanical performance test for tables, applicable for static load validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
