Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3000 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 30 mm | |
| Under-table seated knee clearance height | 690 mm | |
| Leg cross-section dimension | 60 x 30 mm | |
| Chrome foot section height | 200 mm | |
| Central cable channel width | 150 mm | |
| Long-side per-person seating space | 600 mm | |
| Edge banding thickness | 2 mm | |
| Leveling foot adjustment height | 15 mm | |
| End-side seating clearance depth | 400 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed tabletop static load capacity | 300 kg | |
|---|---|---|
| Seating capacity | 10 persons | |
| Product net weight | 75 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Surface moisture resistance | Resistant to 24-hour liquid spill exposure | |
| Frame static vertical load per leg | 120 kg | |
| Anti-wobble lateral stability rating | 30 kg lateral force without deflection | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 18mm high-density particleboard core | |
|---|---|---|
| Tabletop surface finish | 0.6mm thermal-fused light gray melamine laminate | |
| Tabletop edge treatment | 2mm matching color PVC edge banding | |
| Upper leg section | 2mm thick powder-coated matte black steel | |
| Lower leg foot section | 1.5mm thick polished chrome-plated steel | |
| Central channel panel | 1mm powder-coated black steel | |
| Leveling glides | Nylon base with metal threaded stud | |
| Connection hardware | Zinc-plated steel M8 bolts and cam locks | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management channel | Full-length concealed channel running table center for routing power/data cables | |
|---|---|---|
| Leveling foot adjustment | Rotating nylon glides at each leg base to correct uneven floor surfaces | |
| Seating configuration | Supports symmetric placement of 10 ergonomic office chairs around perimeter | |
| Cable access points | Pre-cut openings in central channel for cable pass-through to floor | |
| Fixed frame construction | Non-folding rigid leg-to-top connection for permanent meeting room installation | |
| Surface maintenance | Stain-resistant non-porous top that wipes clean with standard office cleaners | |
| Modesty barrier function | Lower portion of central channel acts as partial modesty panel for seated users | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Corporate boardroom | Designed for 10person formal executive meetings in mid-to-large office spaces | |
|---|---|---|
| Open office collaboration zone | Suitable for team meetings, project discussions and client presentations in open plan offices | |
| Training and seminar room | Supports training sessions and workshop activities requiring large shared work surface | |
| Co-working space meeting area | Durable finish and stable frame withstand high-frequency shared use in co-working facilities |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and stability test methods, applicable to clearance validation | |
| EN 13722:2004 | Furniture test methods for surface resistance to abrasion and staining, applicable to top finish |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop and wood components | |
|---|---|---|
| GB/T 3327-2023 | Performance test standards for office tables, applicable to stability and load requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to tabletop core material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop and wood components; 2. GB/T 3327-2023: Performance test standards for office tables, applicable to stability and load requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to tabletop core material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
