Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 4800 × 1600 × 760 mm | |
|---|---|---|
| Overall dimensions | 4800 x 1600 x 760 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Seating capacity | 16 persons | |
|---|---|---|
| Distributed worksurface load | 320 kg | |
| Concentrated equipment load | 60 kg | |
| Product net weight | 260 kg | |
| End pedestal static load | 180 kg each | |
| Power module occupancy | 2 cable access positions | |
| Recommended floor load | 2.0 kPa | |
| Durability target | 50,000 use cycles for cable covers and access flaps | |
| Warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worksurface | Walnut-look engineered wood board with melamine or veneer-style finish and matching edge banding | |
|---|---|---|
| Edge profile | 50 mm thick soft-rounded edge with impact-resistant banding | |
| End support cabinets | Matte light-grey painted engineered wood panels with walnut accent inserts | |
| Modesty panels | Matte grey rigid panel apron forming a continuous under-table screen | |
| Central support | Rectangular powder-coated metal or high-density composite post | |
| Cable management covers | Brushed silver metal or metallic-finish composite access plates and central channel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated cable routing | Continuous centerline channel with removable cover links both cable ports and the raised media module | |
|---|---|---|
| Countertop access plates | Two access positions provide cable entry, one square plate and one oblong port | |
| Media connectivity station | Raised angled module supports conference room sockets, switching controls or a gooseneck microphone position | |
| Freestanding installation | Floor-standing end cabinets and central post support the table without wall fixing |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Largest carton dimensions | 2500 x 850 x 180 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Boardroom and executive meeting room | Suits 16 participants in management meetings, video conferences and client presentations | |
|---|---|---|
| Conference center and corporate training suite | Supports laptops, conference phones, tabletop microphones and cable-managed power access |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office furniture safety and strength | EN 16139:2013+A1:2019 | |
|---|---|---|
| Office work surface dimensions | EN 527reference dimensions | |
| Formaldehyde emission | EN 13986 E1 classification |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Table structural performance | ANSI/BIFMA X5.5 | |
|---|---|---|
| Sustainability | Recommended references: ANSI/BIFMA e3 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Formaldehyde emission | GB/T 39600 E1 limit | |
|---|---|---|
| Wood furniture quality | GB/T 3324 dimensional stability, edge bonding and finish acceptance criteria | |
| Furniture safety tests | GB/T 10357.5 strength and durability test method |
This product must meet the following technical requirements: 1. Formaldehyde emission: GB/T 39600 E1 limit; 2. Wood furniture quality: GB/T 3324 dimensional stability, edge bonding and finish acceptance criteria; 3. Furniture safety tests: GB/T 10357.5 strength and durability test method; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
