Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Under-table knee clearance height | 680 mm | |
| Leg outer spread at floor (long side) | 2100 mm | |
| Leg outer spread at floor (short side) | 1000 mm | |
| Center cable grommet diameter | 80 mm | |
| Per-seat edge allocation per person | 600 mm | |
| Leg tube diameter | 50 mm | |
| Wood accent bracket thickness | 18 mm | |
| Floor to bottom of leg bracket | 620 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static distributed tabletop load capacity | 227 kg | |
|---|---|---|
| Recommended seating capacity | 6 persons | |
| Tabletop surface abrasion resistance | 2000 cycles | |
| Frame static load rating per leg set | 150 kg | |
| Net product weight | 43 kg | |
| Adjustable foot pad height adjustment range | 10 mm | |
| Warranty period for manufacturing defects | 1 year | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 25mm E1-grade particleboard core | |
|---|---|---|
| Tabletop surface finish | White matte melamine laminate | |
| Tabletop edge banding | 2mm PVC edge matching white top finish | |
| Leg frame structure | Powder-coated white tubular steel | |
| Leg decorative brackets | Brown wood-tone engineered wood veneer | |
| Foot pads | Non-marking TPE rubber adjustable pads | |
| Cable grommet | White ABS plastic grommet | |
| Hardware fasteners | Zinc-plated steel connection bolts | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Center cable management grommet | Recessed cutout routes power, AV, and data cables from tabletop to floor | |
|---|---|---|
| Splayed leg stability design | Angled four-point leg layout eliminates cross-braces to maximize leg room | |
| Leveling foot adjustment | Rotating rubber foot pads compensate for up to 10mm of floor unevenness | |
| Knock-down flat-pack assembly | Tabletop and leg assemblies ship disassembled for reduced shipping volume | |
| Multi-side seating access | No fixed modesty panels or storage pedestals block access to any table edge | |
| Surface cleanability | Non-porous melamine surface wipes clean with standard office disinfectants | |
| Floor protection design | Soft rubber foot pads prevent scuffing and scratching on hard flooring and carpet | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small to medium office meeting rooms | Fits 6 participants for team discussions, client meetings, and project reviews | |
|---|---|---|
| Open office collaboration zones | Open understructure supports flexible chair positioning for impromptu work sessions | |
| Start-up and co-working spaces | Neutral white finish and compact size fit modern shared office aesthetics | |
| Training and presentation spaces | Center cable grommet supports connection to laptops, projectors, and video conferencing equipment | |
| Executive huddle spaces | Sleek splayed leg design works for small leadership team meetings | |
| Breakout meeting areas adjacent to pantries | Stain-resistant surface suits light food and beverage use during informal meetings |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables - Safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 15372:2016 | Office furniture - Durability and stability requirements for non-domestic tables | |
| EN 13722:2004 | Furniture - Test methods for surface resistance to wear and abrasion for table tops |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop and structural components | |
|---|---|---|
| GB/T 3327-2018 | Performance test methods for desks and tables, applicable for static load and stability verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office furniture use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop and structural components; 2. GB/T 3327-2018: Performance test methods for desks and tables, applicable for static load and stability verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office furniture use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
