Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3660 x 1370 x 760 mm | |
|---|---|---|
| Tabletop thickness | 51 mm | |
| End pedestal panel width | 1370 mm | |
| End pedestal panel thickness | 76 mm | |
| Knee clearance height under table | 660 mm | |
| Central cable raceway width | 150 mm | |
| Modesty panel height | 350 mm | |
| Floor clearance under modesty panel | 360 mm | |
| Polished metal edge trim thickness | 2 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed static tabletop load capacity | 136 kg | |
|---|---|---|
| Seating capacity | 12 people | |
| Product net weight | 221 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Adjustable leveling glide adjustment range | 13 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | E1-grade engineered composite wood core | |
|---|---|---|
| Tabletop surface | Dark walnut-toned scratch-resistant thermally fused laminate/wood veneer | |
| Edge trim | Polished chrome-plated metal trim | |
| End pedestal panels | Engineered wood panels with matching dark wood finish | |
| Central cable raceway cover | Matte grey rigid PVC/ABS removable cover | |
| Undertable modesty panel | Matte dark grey powder-coated steel panel | |
| Leveling glides | Nylon base with threaded steel adjusters | |
| Cable access port | Powder-coated steel cable pass-through under table center | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management raceway | Full-length recessed channel with removable cover for routing power, Ethernet, and AV cables | |
|---|---|---|
| Undertable cable pass-through | Central under-table opening for routing cables to floor outlets | |
| Leveling adjustment | Threaded glides at each pedestal base to stabilize table on uneven floors | |
| Open knee space design | Unobstructed legroom along both long sides for unobstructed seated access | |
| Raceway modular accessory compatibility | Supports installation of pop-up power outlets, USB chargers, and data ports at custom positions | |
| Surface maintenance | Stain-resistant non-porous finish for easy cleaning of meeting room spills | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | Designed for 12-person formal executive meetings with integrated power/data access for presentation equipment | |
|---|---|---|
| Training facilities | Supports multi-user laptop and device connection for group training sessions | |
| Commercial office spaces | Matches professional modern office decor with dark wood finish and polished metal trim | |
| Recommended seating configuration | Pair with 12 mid-back conference chairs with armless or narrow arm design to fit around the table perimeter |
EU Market Access Requirements* EN Standards
| EN 15372:2016 | Safety, strength, and durability standard for non-domestic office tables, applicable for performance validation | |
|---|---|---|
| EN 14073-2:2004 | Storage and cable management safety requirements for office furniture, applicable to raceway design |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk and table performance standard for commercial office furniture, recommended for load and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality verification | |
|---|---|---|
| GB/T 18584-2001 | Formaldehyde emission limit for wooden furniture, required for indoor office air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality verification; 2. GB/T 18584-2001: Formaldehyde emission limit for wooden furniture, required for indoor office air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
