Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 1200 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Net product weight | 125 kg | |
| Recommended maximum user weight for work use | 136 kg | |
| Desktop surface abrasion resistance | 2000 cycles | |
| Edge impact resistance | 20 N | |
| Design service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | 25mm high-density particleboard core | |
|---|---|---|
| Desktop surface | Walnut wood veneer with matte polyurethane finish | |
| Support frame | 1.5mm cold-rolled steel with dark grey powder coat | |
| Modesty slat panel | 0.8mm vertical steel slats with matching powder coat | |
| Edge accent trim | Solid walnut wood veneer laminate | |
| Cable tray cover | Brushed aluminum alloy | |
| Base foot pads | 2mm non-slip rubber | |
| Desktop edge banding | 2mm matching PVC edge trim | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Flip-top aluminum tray routes power/data cables from desktop to floor | |
|---|---|---|
| Cantilever support structure | Dual side panels provide 1600mm wide unobstructed knee bay | |
| Slatted modesty panel | Vertical slat design conceals under-desk area without blocking airflow | |
| Smooth rounded desktop edges | Beveled perimeter reduces forearm pressure during extended work | |
| Leveling adjustment | Threaded rubber foot pads adjust up to 10mm to correct uneven floors | |
| Work surface layout | Extra-wide top supports primary monitor, laptop, and meeting document space | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Wide work surface supports executive workflow, meetings, and multiple devices | |
|---|---|---|
| Small conference meeting space | Curved edges accommodate 4 people for quick informal discussions | |
| Corporate management workspace | Premium two-tone finish matches high-end office interior design schemes | |
| Hybrid work home office | Large top supports home office equipment, documents, and video conferencing setup | |
| Reception manager workstation | Elevated design creates professional visual impression for visitor-facing areas |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to safety, strength, and stability requirements for office work desks | |
|---|---|---|
| EN 1335-2:2009 | Applies to clearance dimensions compatibility with standard office task chairs | |
| EN 15372:2008+A1:2016 | Applies to surface durability and mechanical performance for commercial desks |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk structural load, impact, and stability performance testing | |
|---|---|---|
| ANSI/BIFMA e3-2019e | Applies to material sustainability and indoor air quality evaluation criteria |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to desk size, structural strength, and stability requirements for office furniture | |
|---|---|---|
| GB/T 3324-2017 | Applies to surface finish quality, dimensional tolerance, and edge treatment requirements | |
| GB 18584-2001 | Applies to formaldehyde emission limits for wood-based panel furniture components |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to desk size, structural strength, and stability requirements for office furniture; 2. GB/T 3324-2017: Applies to surface finish quality, dimensional tolerance, and edge treatment requirements; 3. GB 18584-2001: Applies to formaldehyde emission limits for wood-based panel furniture components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
