Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3200 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 38 mm | |
| Perimeter edge trim width | 20 mm | |
| Under-table knee clearance height | 690 mm | |
| Under-table knee clearance depth | 1100 mm | |
| Leg assembly splay width at floor | 800 mm | |
| Leg tube cross-section | 80 x 40 mm | |
| Corner radius of tabletop edges | 50 mm | |
| Foot contact pad length | 120 mm | |
| Per-seat linear width allocation | 750 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static distributed tabletop load capacity | 600 kg | |
|---|---|---|
| Net product weight (reference) | 145 kg | |
| Standard seating capacity | 8 people | |
| Edge impact resistance | 200 N | |
| Surface abrasion resistance | 2000 cycles | |
| Adjustable foot height adjustment range | 10 mm | |
| Finish formaldehyde emission grade | E0 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | E0-grade high-density particleboard | |
|---|---|---|
| Tabletop surface finish | Matte walnut woodgrain high-pressure laminate | |
| Perimeter edge trim | Brushed silver aluminum alloy bevel | |
| Leg support structure | 1.5 mm thick brushed silver finished steel tube | |
| Leg connection brackets | 2.5 mm thick powder-coated steel plates | |
| Foot pads | Non-slip nylon glide pads | |
| Fastener hardware | Grade 8.8 zinc-plated steel bolts | |
| Inner support frame | 1.2 mm thick steel cross beams | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Open under-table layout | No central modesty panel obstruction | |
|---|---|---|
| Floor leveling function | Threaded adjustable feet on each leg | |
| Modular cable management compatibility | Pre-drilled port positions accept optional cable grommets | |
| Knock-down assembly design | Two leg assemblies attach to pre-drilled tabletop | |
| Seating configuration flexibility | Supports equal spacing of office chairs around all sides | |
| Edge protection design | Continuous beveled metal/ABS edge | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | 8-person capacity for executive meetings, formal professional appearance for client engagements | |
|---|---|---|
| Open-plan office meeting zones | Sleek modern design complements contemporary open office interiors | |
| Training and seminar spaces | Large work surface holds laptops, notepads and presentation materials for group sessions | |
| Hotel conference facilities | Durable commercial construction for high-traffic guest meeting use | |
| Client reception meeting areas | Walnut and silver finish conveys professional brand image for visitor meetings | |
| Project team collaboration spaces | Unobstructed legroom and wide surface supports team brainstorming and document review |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, applicable to structural stability and safety requirements | |
|---|---|---|
| EN 15372:2016 | Furniture - Strength, durability and safety for non-domestic tables, commercial use standard | |
| EN 13722:2004 | Furniture - Test methods for table stability, applicable to splayed leg structure verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products, applicable to table load, stability and durability testing for office use | |
|---|---|---|
| ANSI/BIFMA X7.1-2022 | Standard for formaldehyde and TVOC emissions, applicable to low-emission office furniture acceptance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop panel performance | |
|---|---|---|
| GB/T 3327-2016 | Test methods for furniture tables, applicable to structural stability and load testing | |
| GB 18584-2001 | Limit of formaldehyde emission for wooden furniture, applicable to panel material acceptance | |
| GB/T 4893.8-2013 | Surface wear resistance test for furniture finishes, applicable to laminate durability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop panel performance; 2. GB/T 3327-2016: Test methods for furniture tables, applicable to structural stability and load testing; 3. GB 18584-2001: Limit of formaldehyde emission for wooden furniture, applicable to panel material acceptance; 4. GB/T 4893.8-2013: Surface wear resistance test for furniture finishes, applicable to laminate durability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
