Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 80 mm | |
| Undertable knee clearance height | 670 mm | |
| Pedestal base width (each end) | 350 mm | |
| Central cable grommet cutout size | 240 x 80 mm | |
| Long-side per-user seating space | 600 mm | |
| Grey modesty panel height | 420 mm | |
| Table edge overhang past pedestals | 120 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 450 kg | |
|---|---|---|
| Recommended maximum seating capacity | 6 people | |
| Surface scratch resistance rating | 2000 cycles | |
| Surface stain resistance class | Class 2 | |
| Product net weight | 67 kg | |
| Commercial use warranty period | 5 years | |
| Surface water resistance duration | 24 hours | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 25mm thickness P2 grade engineered wood particleboard | |
|---|---|---|
| Tabletop surface finish | Walnut wood grain thermofused laminate, 0.6mm thickness wear layer | |
| Table edge treatment | 2mm thickness PVC edge banding, color matched to walnut finish | |
| End pedestal bases | Fluted engineered wood panels, walnut veneer finish, 30mm panel thickness | |
| Central modesty panel | Matte light grey laminated MDF panel, 18mm thickness | |
| Central cable grommet | Brushed silver aluminum frame with flip-open plastic cover | |
| Internal support frame | 1.5mm thickness square steel tube frame under tabletop | |
| Base bottom glides | Adjustable nylon leveling glides, 10mm adjustment range | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management | Flip-top grommet routes power, HDMI, and data cables from tabletop to floor | |
|---|---|---|
| Undertable leg clearance | Full unobstructed 1700mm clear span between pedestals for seated users | |
| Leveling adjustment | Rotating nylon glides adjust up to 10mm to stabilize table on uneven carpet or hard floors | |
| Surface utility | Smooth non-porous surface supports laptops, meeting materials, and tabletop conferencing devices | |
| Seating configuration compatibility | Accommodates 3 cantilever or wheeled guest chairs per long side, 1 per short end | |
| Modesty coverage | Central grey panel blocks view of under-table legs and cables from opposite seating position | |
| Assembly mechanism | Knock-down construction with cam-lock and bolt fasteners connecting tops to bases | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small corporate boardroom | Serves 6 meeting attendees for executive discussions, client presentations, and team reviews | |
|---|---|---|
| Open office meeting area | Functions as a dedicated collaborative space for team standups and project workshops | |
| Private office guest meeting zone | Pairs with executive guest seating for manager one-on-one or small group meetings | |
| Training room small group setup | Supports small group training sessions with laptop connectivity and document workspace | |
| Recommended seating pairing | Pairs with cantilever-frame guest chairs or mid-back conference chairs with armrests | |
| Surface care requirement | Clean with non-abrasive neutral cleaner, avoid harsh solvents to preserve laminate finish |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks - Part 1: Dimensions, applicable to work height and clearance requirements | |
|---|---|---|
| EN 15372:2016 | Furniture - Strength, durability and safety - Requirements for non-domestic tables, applicable to structural load testing | |
| EN 13722:2004 | Furniture - Assessment of surface resistance to cold liquids, applicable to stain resistance performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for Office Furnishings - Desk Products, applicable to structural safety and load testing for commercial use | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture Sustainability Standard, applicable to material emissions and environmental performance criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop substrate and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to structural engineered wood substrate performance | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture, applicable to formaldehyde emission limits |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop substrate and finish quality; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to structural engineered wood substrate performance; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture, applicable to formaldehyde emission limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
