Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 760 mm | |
|---|---|---|
| Tabletop thickness | 50 mm | |
| Cylindrical leg diameter | 60 mm | |
| Central modesty panel dimensions | 800 x 400 x 680 mm | |
| Seated knee clearance under tabletop | 690 mm | |
| Central power grommet dimensions | 250 x 100 mm | |
| Brass accent ring width on legs | 10 mm | |
| Leg floor glide diameter | 30 mm | |
| Cable pass-through notch width at modesty base bottom | 200 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed static tabletop load capacity | 450 kg | |
|---|---|---|
| Recommended seating capacity | 8 people | |
| Surface abrasion resistance | 2000 cycles | |
| Leveling adjustment range per foot glide | 15 mm | |
| Product net weight | 120 kg | |
| Finish impact resistance | 1.5 m drop | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 25mm high-density MDF substrate | |
|---|---|---|
| Tabletop surface | Light oak wood-look high-pressure laminate | |
| Tabletop edge banding | 2mm thick matte black PVC edge trim | |
| Support legs | 1.5mm thick powder-coated carbon steel cylindrical tubes | |
| Leg decorative accents | Brass-plated steel trim rings at top and bottom of each leg | |
| Central modesty panel | 18mm thick melamine-faced particleboard with black finish | |
| Floor glides | Nylon non-slip adjustable leveling feet | |
| Cable management port | ABS plastic housing with flip cover | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated connectivity | Central tabletop port accepts power, USB-A, USB-C and HDMI cables | |
|---|---|---|
| Under-table cable routing | Central modesty panel base notch routes cables to floor outlets | |
| Floor leveling | Adjustable nylon glides on each leg compensate for uneven floor surfaces | |
| Dual-side seating access | Open knee clearance on both long sides accommodates attendees across full table length | |
| Fixed working height | 760mm seated working height aligns with standard office task chair dimensions | |
| Modesty screening | Central panel blocks leg visibility between attendees seated across the table | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | Fits 8 attendees for formal executive meetings and presentations | |
|---|---|---|
| Medium office meeting rooms | Serves team collaboration, client interviews and internal project discussions | |
| Training and seminar spaces | Accommodates training materials and connected devices for instructor-led sessions | |
| Co-working facility meeting pods | Provides professional shared meeting space with integrated device charging | |
| Government and institutional meeting spaces | Meets commercial durability requirements for frequent public sector use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for fixed-height commercial tables | |
|---|---|---|
| EN 15372:2016 | Furniture mechanical safety requirements for non-domestic seating and tables |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for tabletop structural stability | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard specification for furniture-grade substrate used in support panels | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood-based furniture components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for tabletop structural stability; 2. GB/T 4897.3-2003: Particleboard specification for furniture-grade substrate used in support panels; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood-based furniture components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
