Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 1200 x 762 mm | |
|---|---|---|
| Tabletop thickness | 38 mm | |
| Pedestal end panel width | 400 mm | |
| Central cable trough width | 150 mm | |
| Under-table knee clearance height | 680 mm | |
| Vertical slat thickness | 12 mm | |
| Tabletop overhang on long sides | 80 mm | |
| Silver foot trim height | 10 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Static tabletop uniform load capacity | 500 kg | |
|---|---|---|
| Seating capacity | 10 people | |
| Product net weight | 127 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Leveling foot adjustment range | 15 mm | |
| Recommended commercial warranty | 60 months | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | High-density particleboard core | |
|---|---|---|
| Tabletop finish | Thermally fused dark walnut wood grain laminate | |
| Table edge treatment | 2mm thick matching PVC edge banding | |
| End pedestal panels | 18mm thick black powder-coated MDF | |
| Modesty panel slats | Vertical powder-coated steel slats with black finish | |
| Base accent trim | Brushed silver metallic edge trim at pedestal feet | |
| Fastening hardware | Zinc-plated M8 hex socket assembly bolts | |
| Leveling feet | Reinforced nylon base with threaded steel stem | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management trough | Recessed full-length channel with removable cover for power/data routing | |
|---|---|---|
| End pedestal support structure | Fully enclosed box supports at each table end for maximum span stability | |
| Open slat modesty panel | Full-width vertical slat panel between pedestals to block leg visibility | |
| Adjustable leveling feet | Threaded feet at each pedestal corner to correct uneven floor surfaces | |
| Modular power/data compatibility | Trough accepts standard 80mm wide power/USB/AV modules for meeting room use | |
| KD assembly design | Flat-pack knock-down construction for on-site assembly with standard tools | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | Designed for 10person executive meetings with integrated AV power access | |
|---|---|---|
| Medium meeting rooms | Sized for team collaboration, client presentations, and internal review sessions | |
| Training facilities | Stable surface for training materials, laptops, and presentation equipment | |
| Hybrid work spaces | Central cable trough supports video conference equipment and device charging | |
| Hotel conference centers | Durable commercial construction suitable for high-traffic event use |
EU Market Access Requirements* EN Standards
| EN 527-3:2003 | Office work tables - test methods for safety and structural stability | |
|---|---|---|
| EN 15372:2016 | Furniture - strength, durability and safety for non-domestic tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products, covering static load, stability, durability for commercial tables |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for table structural integrity | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable for tabletop substrate performance | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for table structural integrity; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable for tabletop substrate performance; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
