Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 760 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Under-table knee clearance height | 710 mm | |
| Leg tubing section size | 60 x 30 mm | |
| Cable grommet opening size | 160 x 80 mm | |
| Edge banding thickness | 2 mm | |
| Leg splay offset from table corner | 120 mm | |
| Long-side seating clearance per person | 600 mm | |
| Short-side seating clearance per person | 600 mm | |
| Floor glide adjustment range | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed tabletop static load capacity | 150 kg | |
|---|---|---|
| Total net product weight | 70 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Maximum recommended seating capacity | 6 people | |
| Leg frame static load per leg | 120 kg | |
| Warranty period for commercial use | 5 years | |
| Available finish color options | 30 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | Melamine-faced particleboard (MFC) | |
|---|---|---|
| Tabletop edge trim | 2mm thick PVC edge banding | |
| Leg construction | 1.5mm thick rectangular steel tubing | |
| Cable grommet | ABS plastic with brushed silver finish cover | |
| Floor contact glides | Nylon with non-slip rubber pad | |
| Assembly hardware | Zinc-plated steel bolts and cam locks | |
| Surface finish coating | Scratch-resistant melamine laminate | |
| Internal support rails | 1.2mm thick steel cross bracing | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management grommet | Recessed dual-port pass-through routes power/data cables from surface to floor | |
|---|---|---|
| Leveling adjustment | Adjustable foot glides compensate for 10mm floor unevenness | |
| Knock-down assembly | Flat-pack design requires bolted leg attachment with basic screwdriver | |
| Seating access | Open under-table clearance on all sides supports rolling task chair entry/exit | |
| Surface use case | Smooth non-porous top supports laptops, documents, and meeting materials | |
| Cable access upgrade compatibility | Grommet cutout accepts optional power/HDMI/network module inserts | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small office meeting rooms | Fits 6 participants for team discussions, client meetings, and project reviews | |
|---|---|---|
| Open office collaboration zones | Open under-clearance supports flexible rolling chair arrangement for ad-hoc work | |
| Startup and co-working spaces | Modern light wood and off-white finish matches contemporary workspace aesthetics | |
| Training rooms | Stable surface supports laptops, training materials, and note-taking for group sessions | |
| Small conference spaces in professional services firms | Professional, understated design suitable for client-facing meetings |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for structural performance | |
|---|---|---|
| EN 1335-2:2009 | Office furniture stability for work surfaces, applicable for tip resistance testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable for commercial durability and load testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for tabletop structural integrity | |
|---|---|---|
| GB/T 3327-2018 | Performance requirements for office desks and tables, applicable for load and stability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for tabletop core material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for tabletop structural integrity; 2. GB/T 3327-2018: Performance requirements for office desks and tables, applicable for load and stability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for tabletop core material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
