Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 4200 x 1400 x 750 mm | |
|---|---|---|
| Tabletop thickness | 50 mm | |
| Central cable raceway width | 200 mm | |
| Under-table knee clearance height | 680 mm | |
| Support base width | 300 mm | |
| Support base spacing (long side) | 1200 mm | |
| Edge overhang from base (long side) | 100 mm | |
| Chair access clearance per seat | 700 mm | |
| Tabletop corner radius | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Seating capacity | 10 people | |
|---|---|---|
| Desktop concentrated static load | 300 kg | |
| Uniform surface load capacity | 150 kg/m² | |
| Net product weight | 221 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Edge impact resistance | 180 N | |
| Warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 25mm E1 grade MDF core | |
|---|---|---|
| Tabletop surface finish | Dark walnut wood veneer with matte lacquer | |
| Tabletop edge banding | 2mm matching wood veneer edge | |
| Support panel bases | 50mm engineered wood with matching walnut finish | |
| Central cable raceway cover | Matte black rigid PVC panel | |
| Under-table modesty panel | 25mm matte black engineered wood panel | |
| Floor protection pads | 6mm non-slip rubber pads under each base | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management raceway | Continuous recessed channel routing power/data cables along full table length | |
|---|---|---|
| Cable access points | Removable raceway cover allows cable insertion at any seat position | |
| Seating layout support | Unobstructed perimeter supports chairs on both long sides and both ends | |
| Surface stability | Three spaced panel bases minimize tabletop deflection under heavy load | |
| Modesty coverage | Full-length under-table panel blocks view of legs from opposite seating side | |
| Floor leveling | Hidden adjustable glides under each base compensate for uneven carpeted floors | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Corporate boardroom | Fits executive board spaces for 10-person leadership and client meetings | |
|---|---|---|
| Open-plan office meeting zone | Serves large team collaboration, training and video conferencing sessions | |
| Government/institutional meeting space | Durable construction supports high-frequency public sector meeting use | |
| Commercial office tenant spec suite | Coordinates with dark wood office casegoods for premium leased office fit-outs | |
| Conference center function room | Scalable configuration for corporate events and multi-group meetings |
EU Market Access Requirements* EN Standards
| EN 527-2:2002 | Office work tables safety and strength requirements, applicable for structural performance verification | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for surface resistance to abrasion and impact, applicable for finish durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products, applicable for static load, stability and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish qualityAcceptance inspection | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office tables, applicable for load and stability verification | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish qualityAcceptance inspection; 2. GB/T 3327-2016: Performance test methods for office tables, applicable for load and stability verification; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
