Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 30 mm | |
| Leg section size | 60 x 60 mm square | |
| Leg wall thickness | 1.5 mm | |
| Under-table knee clearance height | 670 mm | |
| Long-side seating edge length per side | 1800 mm | |
| End-side seating edge length per end | 900 mm | |
| Central modesty panel dimensions | 1200 x 400 x 670 mm | |
| Cable slot opening size | 300 x 80 mm | |
| Adjustable foot pad height adjustment range | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop distributed static load capacity | 120 kg | |
|---|---|---|
| Recommended maximum seated user count | 8 people | |
| Product net weight | 70 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Leg structure static load rating per leg | 80 kg | |
| Warranty period for manufacturing defects | 18 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | High-density particleboard core | |
|---|---|---|
| Tabletop surface | Matte grey melamine laminate | |
| Tabletop edge banding | 2mm thick PVC edge banding | |
| Support legs | Powder-coated dark grey square steel tubing | |
| Central modesty panel | Matte black engineered wood panel with steel frame | |
| Leveling feet | Reinforced nylon with threaded steel insert | |
| Hardware connectors | Zinc-plated steel cam lock and bolt hardware | |
| Cable slot cover | Matte black ABS plastic flip cover | |
| Surface coating on metal parts | 60μm epoxy powder coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Central recessed slot with flip cover | |
|---|---|---|
| Floor leveling | Threaded adjustable foot pads on all leg bases | |
| Structural rigidity | Central full-depth modesty support panel | |
| Assembly format | Flat-pack knock-down construction | |
| Seating accommodation | Clear under-table perimeter space | |
| Surface utility | Matte non-glare tabletop finish | |
| Color option availability | 2 standard finishes | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small to medium meeting rooms | Seats 8participants for team discussions and project updates | |
|---|---|---|
| Open office collaboration zones | Provides a fixed shared workspace for group laptop work | |
| Corporate boardrooms for 8-person meetings | Fits standard executive meeting layouts with presentation space | |
| Training and seminar rooms | Supports instructor-led sessions with device charging cable access | |
| Coworking space common areas | Durable commercial construction for high-frequency daily use | |
| Home office large meeting spaces | Accommodates multi-person video calls and document collaboration |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for commercial office conference use | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and mechanical stability requirements, applicable for clearance checks | |
| EN 13722:2004 | Furniture strength and durability for office seating-adjacent tables, applicable for load rating | |
| EN 717-1:2004 | Formaldehyde emission testing for wood-based panels, applicable for material emission compliance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5 Load Test 5 | Vertical static load test for tabletop, applies 113kgf for 1 hour at center |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for tabletop and panel components | |
|---|---|---|
| GB/T 3327-2017 | Dimensions and tolerance requirements for office tables, applicable for height and clearance verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for particleboard core material | |
| GB/T 4893.8-2013 | Surface wear resistance test for furniture finishes, applicable for melamine top durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for tabletop and panel components; 2. GB/T 3327-2017: Dimensions and tolerance requirements for office tables, applicable for height and clearance verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for particleboard core material; 4. GB/T 4893.8-2013: Surface wear resistance test for furniture finishes, applicable for melamine top durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
