Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 1150 x 760 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Edge banding thickness | 2 mm | |
| Knee clearance height | 620 mm | |
| Knee clearance width (central opening) | 700 mm | |
| Knee clearance width (side openings) | 600 mm | |
| Central cable channel length | 1800 mm | |
| Cable channel opening width | 80 mm | |
| Base cabinet height | 700 mm | |
| Desktop overhang (front/back) | 80 mm | |
| Desktop corner radius | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet door hinge cycle rating | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Product net weight | 300 kg | |
| Recommended user weight capacity | 150 kg | |
| Warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | High-density fiberboard core | |
|---|---|---|
| Desktop surface | Walnut-toned solid wood veneer | |
| Base cabinet panels | Painted MDF with vertical fluted detailing | |
| Base finish | Matte polyurethane lacquer coating | |
| Block feet | Solid hardwood with dark stain | |
| Cable channel cover | Matte light cream solid surface panel | |
| Drawer slides | Cold-rolled steel full-extension hardware | |
| Cabinet hinges | Zinc-alloy soft-close concealed hinges | |
| Edge banding | Matching wood veneer with rounded profile | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management channel | Recessed top slot with removable cover, routes power/data cables | |
|---|---|---|
| Integrated base storage | Enclosed cabinet compartments behind fluted front panels, includes 4 drawers | |
| Soft-close drawer operation | Drawers glide on full-extension slides and close silently without slamming | |
| Arched knee clearance openings | Three cutouts under base provide legroom for user and two side guests | |
| Floor protection feet | Hardwood block feet elevate base to prevent scuffing and floor contact damage | |
| Rounded edge safety design | All desktop corners and edges are radiused to reduce impact injuries | |
| Cable grommet access | Pre-drilled pass-through points connect desktop channel to under-desk cable tray | |
| Locking storage option | Central drawer and cabinet doors support optional keyed lock for document security | |
| Block foot height | 20 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Primary use for CEO/senior manager workspace, provides ample work and storage space | |
|---|---|---|
| Conference side workspace | Suitable as leadership meeting room side table for document review and equipment placement | |
| High-end home office | Fits luxury residential study spaces with classic wood aesthetic and cable management | |
| Reception VIP lounge | Appropriate for premium visitor greeting areas with decorative display surface | |
| Recommended supporting furniture | Pair with matching executive leather chair, side credenza and bookcase for coordinated office set | |
| User position | Seated at central arched opening facing front, with 760mm work height matching standard ergonomic office chairs | |
| Surface cleaning | Wipe-clean lacquered surface suitable for daily office use with minimal maintenance |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for commercial use evaluation | |
|---|---|---|
| EN 15372:2016 | Office furniture storage units durability and strength, applicable to base cabinet assessment | |
| EN 13722:2004 | Furniture surface resistance to abrasion and staining, applicable to finish performance checks |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products durability and safety standard, applicable for commercial office performance testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural quality checks | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard/fiberboard for furniture use, applicable to substrate material acceptance | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood furniture, mandatory safety check |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural quality checks; 2. GB/T 4897.3-2003: Particleboard/fiberboard for furniture use, applicable to substrate material acceptance; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood furniture, mandatory safety check; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
