Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3200 x 1380 x 750 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Leg spread (front-to-back) | 1100 mm | |
| Knee clearance height (under top) | 690 mm | |
| Knee clearance width (between front legs) | 2800 mm | |
| Edge profile | 2 mm radius chamfered edge | |
| Wood accent joint width | 180 mm | |
| Floor contact pad diameter | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed tabletop static load | 260 kg | |
|---|---|---|
| Single-point concentrated load | 50 kg | |
| Seating capacity | 10 persons | |
| Tabletop surface abrasion resistance | 2000 cycles | |
| Surface heat resistance | 80 °C | |
| Leg frame static stability load | 450 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | High-density particleboard core | |
|---|---|---|
| Tabletop surface finish | Matte white thermally fused melamine laminate | |
| Leg frame material | 1.5 mm thick cold-rolled steel tube | |
| Leg finish | White matte powder coating | |
| Leg joint accents | Solid oak veneer wrapped MDF | |
| Edge banding | 2 mm thick PVC edge | |
| Floor protection pads | TPE non-marring glides | |
| Internal support frame | 1.2 mm thick steel cross bracing | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Structure type | Fixed freestanding assembly | |
|---|---|---|
| Assembly requirement | Knock-down construction | |
| Surface function | Flat continuous work surface | |
| Stability feature | Triangular wishbone leg bracing | |
| Cable management compatibility | Pre-drilled grommet-ready surface | |
| Floor protection | Height-adjustable glide pads | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | Formal meeting spaces for 10person executive meetings and presentations | |
|---|---|---|
| Training rooms | Configurable space for internal training, workshops, and group activities | |
| Open office collaboration zones | Dedicated long table for cross-team collaborative work sessions | |
| Professional service offices | Client meeting spaces for law, consulting, and design firms | |
| Higher education meeting spaces | Faculty and administrative meeting rooms in campus buildings |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables, safety and dimensional requirements for office table products | |
|---|---|---|
| EN 15372:2016 | Office furniture, strength, durability and stability requirements for tables | |
| EN 13722:2004 | Furniture, test methods for surface resistance to abrasion and wear |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for commercial office table performance testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to tabletop panel construction | |
|---|---|---|
| GB/T 3327-2018 | Office furniture desks and tables, specifies dimensional and stability requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor commercial use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to tabletop panel construction; 2. GB/T 3327-2018: Office furniture desks and tables, specifies dimensional and stability requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor commercial use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
