Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3200 x 1400 x 750 mm | |
|---|---|---|
| Tabletop thickness | 38 mm | |
| Central cable channel width | 200 mm | |
| Modesty panel height | 600 mm | |
| Support panel thickness | 80 mm | |
| Knee clearance height | 650 mm | |
| Knee clearance depth under table | 400 mm | |
| Corner radius | 50 mm | |
| Per-seat table edge length per side | 800 mm | |
| Tabletop overhang beyond base | 100 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed tabletop static load capacity | 500 kg | |
|---|---|---|
| Maximum seating capacity | 10 people | |
| Surface finish abrasion resistance | 2000 cycles | |
| Surface stain and heat resistance | Class B3 | |
| Reference net weight | 240 kg | |
| Base panel static load per support | 200 kg | |
| Warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 25mm thick high-density particleboard core | |
|---|---|---|
| Tabletop surface finish | Dark walnut woodgrain high-pressure laminate | |
| Tabletop edge banding | 2mm thick matching PVC rounded edge banding | |
| Base and modesty panel core | 18mm thick MDF core panel | |
| Base and modesty finish | Matte light champagne/beige polyurethane lacquer | |
| Connection hardware | Zinc-plated steel cam lock and confirmat screw connectors | |
| Central cable channel liner | Powder-coated steel cable trough | |
| Bottom foot pads | 6mm thick non-slip rubber pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management | Full-length recessed 200mm wide steel trough running entire table center | |
|---|---|---|
| Cable access points | Removable channel cover with cutouts for power/data outlet installation | |
| Modesty coverage | Full-height solid panels along both long sides blocking under-table visibility | |
| Seating access | 100mm tabletop overhang on all sides allowing chair arm clearance | |
| Assembly structure | Knockdown panel construction with cam-lock connections for on-site assembly | |
| Cable routing path | Open under-table space between supports allowing vertical cable drops to floor outlets | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Corporate boardrooms and executive meeting rooms | |
|---|---|---|
| Secondary application space | Large private executive offices and training rooms | |
| Recommended supporting furniture | Upholstered executive office chairs with casters | |
| Compatible AV equipment | Tabletop conference microphones, embedded power outlets and video conferencing hardware | |
| User group | Corporate teams, executive leadership and client meeting groups | |
| Design style fit | Modern contemporary office interiors with neutral color palettes |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural load testing | |
|---|---|---|
| EN 14073-2:2004 | Office storage and work surfaces electrical safety for integrated cable and power accessories | |
| EN 13722:2004 | Furniture test methods for surface resistance to abrasion, staining and heat damage |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products covering static load, stability and durability testing for office tables | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and environmental performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to table structural stability and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to tabletop core material performance requirements | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wooden furniture, mandatory for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to table structural stability and finish quality; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to tabletop core material performance requirements; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wooden furniture, mandatory for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
