Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3200 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Corner radius | 50 mm | |
| Under-table knee clearance height | 715 mm | |
| Central cable channel length | 1800 mm | |
| Central cable channel width | 120 mm | |
| Leg tube diameter | 38 mm | |
| Leg splay span per support set | 800 mm | |
| Edge banding thickness | 2 mm | |
| Leveling foot adjustment range | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 400 kg | |
|---|---|---|
| Product net weight | 68 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended seating capacity | 8 persons | |
| Leveling foot load per leg | 100 kg | |
| Cable channel cable capacity | 12 cables | |
| Commercial warranty period | 5 years | |
| Seating capacity clearance per position | 600 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | E1 grade particleboard core | |
|---|---|---|
| Tabletop finish | Light oak melamine laminate | |
| Edge banding | 2mm thick ABS edge trim | |
| Support legs | Polished chrome plated steel tube | |
| Under-frame support beam | 1.5mm thick powder coated steel | |
| Cable channel housing | Brushed aluminum alloy | |
| Leveling feet | Nylon base with steel threaded stem | |
| Power module faceplate | Flame-retardant ABS plastic | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management | Recessed linear channel routes cords from tabletop to floor | |
|---|---|---|
| Integrated power access | Pop-up modules provide AC power, USB-A, USB-C, HDMI and RJ45 ports | |
| Floor leveling adjustment | Threaded feet adjust 10mm to compensate for uneven floors | |
| Open under-table legroom | Unobstructed 715mm clearance without modesty panels | |
| Knock-down assembly | Tabletop and legs disassemble for flat-pack shipping | |
| Rounded corner safety | Soft 50mm radius corners reduce impact injury risk | |
| Cable retention | Internal clips secure wiring to prevent tangling under the tabletop | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | Fits 8-person formal meeting spaces with central device connectivity | |
|---|---|---|
| Open office collaboration zones | Supports team brainstorming, laptop work and document review | |
| Training rooms | Provides ample surface space for materials and connected presentation devices | |
| Small conference suites | Serves client meeting spaces with minimalist professional aesthetic | |
| Co-working shared spaces | Accommodates flexible multi-user booking for mixed work activities |
EU Market Access Requirements* EN Standards
| Office table safety requirement | EN 527:2002+A1:2019 | |
|---|---|---|
| Formaldehyde emission standard | EN 13986:2004+A1:2015 E1 | |
| Surface wear resistance | EN 14322:2017 |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| Formaldehyde emission limit | GB/T 39600E1 grade | |
|---|---|---|
| Table stability test | GB/T 10357.1 | |
| Surface durability test | GB/T 4893.9 |
This product must meet the following technical requirements: 1. Formaldehyde emission limit: GB/T 39600E1 grade; 2. Table stability test: GB/T 10357.1; 3. Surface durability test: GB/T 4893.9; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
