Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 1600 x 760 mm | |
|---|---|---|
| Tabletop thickness | 50 mm | |
| Central cable panel length | 1800 mm | |
| Central cable panel width | 350 mm | |
| End leg width | 600 mm | |
| End leg fluted accent section width | 200 mm | |
| Under-table knee clearance height | 710 mm | |
| Per-seat edge allocation | 760 mm | |
| Rounded corner radius | 150 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Seating capacity | 8 people | |
|---|---|---|
| Distributed tabletop static load | 450 kg | |
| Point load per tabletop section | 100 kg | |
| Finish scratch resistance | 2000 cycles | |
| Product net weight | 222 kg | |
| Stability lateral load rating | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 25mm high-density MDF core with 0.6mm wood veneer overlay | |
|---|---|---|
| Tabletop edge finish | Soft-radius PU edge banding matching veneer tone | |
| Base panel material | Matte light beige lacquered 18mm MDF panels | |
| End leg fluted accent | Vertical slat solid wood veneer trim matching tabletop finish | |
| Internal support frame | 2mm thick rectangular steel tube subframe | |
| Central cable panel cover | Matte beige ultra-fiber leatherette over MDF core | |
| Cable access grommet | Brushed black ABS plastic wire port | |
| Bottom foot pads | 8mm thick adjustable non-slip rubber pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management | Recessed trough routes power/HDMI/network cables from floor to tabletop devices | |
|---|---|---|
| Central access port | 1 oval cutout in center panel for cable pass-through | |
| Fixed panel leg support | Dual end panel legs with intermediate side supports for rigid structure | |
| Leveling adjustment | Adjustable rubber foot pads compensate for 15mm floor unevenness | |
| Surface maintenance | Non-porous PU finish allows wipe-clean sanitization between meetings | |
| Modular power compatibility | Trough fits 2 AC outlets, 1 HDMI, 1 RJ45 network, 2 USB chargers | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Corporate boardroom | Seats 8 attendees for executive meetings and decision-making sessions | |
|---|---|---|
| Open office collaboration zone | Supports cross-department team meetings and project reviews | |
| Training and presentation room | Accommodates presenter-led training sessions with shared device connectivity | |
| Executive client meeting space | Dual-tone premium aesthetic creates professional impression for client visits | |
| Small conference suite | Fits rooms sized 5m x 4m with adequate chair circulation space around perimeter |
EU Market Access Requirements* EN Standards
| EN 527-3:2003 | Office tables test methods for stability and mechanical strength, applicable for commercial use | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for surface resistance to abrasion and liquid staining |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for static load, durability, and stability performance |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to table structural stability and finish | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard/MDF requirements for furniture-grade substrate formaldehyde emission limits | |
| GB 28007-2011 | Safety requirements for office furniture, addressing sharp edges and structural load capacity |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to table structural stability and finish; 2. GB/T 4897.3-2015: Particleboard/MDF requirements for furniture-grade substrate formaldehyde emission limits; 3. GB 28007-2011: Safety requirements for office furniture, addressing sharp edges and structural load capacity; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
