Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 38 mm | |
| Leg splay angle from vertical | 18 degrees | |
| End dark panel length (each end) | 300 mm | |
| Long-side under-table knee clearance height | 690 mm | |
| Adjustable leveling foot height adjustment range | 15 mm | |
| Leg spacing along long sides | 800 mm | |
| Corner radius (rounded tabletop edges) | 30 mm | |
| Leg tube diameter | 60 mm | |
| Cross-side seated knee clearance width | 1100 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total tabletop static load capacity | 300 kg | |
|---|---|---|
| Seating capacity | 6 persons | |
| Surface scratch resistance rating | 2000 cycles | |
| Net product weight | 75 kg | |
| Surface heat resistance (short contact) | 120 °C | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop central section | Light wood-grain melamine laminate over E1 grade MDF core | |
|---|---|---|
| Tabletop end panels | Matte black melamine laminate over matching composite core | |
| Table edge banding | 2 mm thick black PVC edge trim with rounded profile | |
| Support legs | Powder-coated matte black steel tube with textured finish | |
| Leveling feet | Chrome-plated steel threaded stem with non-slip rubber pad | |
| Core panel density | 720 kg/m³ | |
| Surface coating (legs) | Epoxy polyester powder coat, 60 micron thickness | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Leveling adjustment | Threaded steel feet adjust 15 mm vertically to stabilize on uneven floors | |
|---|---|---|
| Seating access | Open understructure without modesty panels allows seating on all four sides | |
| Surface function | Smooth non-porous laminate surface supports writing, laptop use and document layout | |
| Leg stability design | Splayed leg geometry distributes load outward to reduce wobble during meetings | |
| Floor protection | Rubber pads on leveling feet prevent hard floor scratching and skidding | |
| Assembly configuration | Knock-down leg attachment to pre-finished tabletop for on-site assembly | |
| Cable management compatibility | Pre-drilled leg mounts support optional under-table cable clips | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small corporate meeting rooms | Fits 6 attendees for team meetings and project reviews | |
|---|---|---|
| Open office collaborative zones | Low-profile open design supports informal group work and huddles | |
| Training and seminar spaces | Durable scratch-resistant surface withstands frequent daily use | |
| Small startup workspaces | Modern two-tone finish matches contemporary open-plan office aesthetics | |
| Home office multi-use spaces | Standard 750mm height pairs with standard office task chairs |
EU Market Access Requirements* EN Standards
| Office furniture strength and stability | EN 15372:2016 level 2 for contract office use | |
|---|---|---|
| Laminate surface wear resistance | EN 438:2016 abrasion resistance ≥350 revolutions |
US and Canada office-furniture standards
| Conference table static load test | ANSI/BIFMA X2021desk/table vertical load test 136 kg per 760mm | |
|---|---|---|
| Table leg stability test | ANSI/BIFMA X2021horizontal stability 156 N force at table edge |
Standards applicable to China-market projects
| Tabletop formaldehyde emission | GB/T 17657E1 limit ≤0.124 mg/m³ | |
|---|---|---|
| Furniture stability | GB/T 10357.1vertical and horizontal load stability test | |
| Surface coating adhesion | GB/T 4893.4cross-cut adhesion grade 1 minimum |
This product must meet the following technical requirements: 1. Tabletop formaldehyde emission: GB/T 17657E1 limit ≤0.124 mg/m³; 2. Furniture stability: GB/T 10357.1vertical and horizontal load stability test; 3. Surface coating adhesion: GB/T 4893.4cross-cut adhesion grade 1 minimum; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
