Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1400 × 800 × 410 mm | |
|---|---|---|
| Tabletop thickness | 38 mm | |
| Wood inlay strip width | 200 mm | |
| Tabletop overhang (front/back) | 80 mm | |
| Tabletop overhang (left/right ends) | 120 mm | |
| Central under-table gap width | 620 mm | |
| Floor clearance under base | 20 mm | |
| Corner radius of tabletop | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed tabletop static load capacity | 50 kg | |
|---|---|---|
| Product net weight | 37 kg | |
| Surface scratch resistance rating | 3000 cycles | |
| Supported finish color count | 2 | |
| Surface heat resistance | 80 °C | |
| Warranty period | 365 days | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer tabletop panel | 18mm MDF substrate with dark matte lacquer finish | |
|---|---|---|
| Central tabletop inlay | 0.6mm dark wood veneer over MDF core | |
| Pedestal block bodies | 25mm particle board with matching dark matte lacquer | |
| Base plinth feet | Hard plastic dark grey glides | |
| Tabletop edge detailing | Stepped layered lacquer trim | |
| Internal joint connectors | 50mm cam lock and dowel hardware | |
| Lacquer coating thickness | 0.15mm polyurethane matte topcoat | |
| Substrate moisture content | 10% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Surface placement function | Flat load-bearing top for drinks, decor, books and small household items | |
|---|---|---|
| Central under-table open gap | Unobstructed floor-level space for storage of low baskets or ottomans | |
| Floor protection design | Recessed plastic glides on plinth feet prevent scuffing on hard flooring | |
| Cleaning compatibility | Smooth non-porous lacquer surface wipes clean with damp soft cloth | |
| Assembly requirement | Knock-down assembly with included cam hardware connecting top to pedestals | |
| Weight distribution design | Dual end pedestal supports eliminate wobble across full tabletop span | |
| Pedestal block length (each end) | 350 mm | |
| Pedestal block height | 280 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Suitable interior styles | Modern minimalist, contemporary light luxury, urban modern interiors | |
|---|---|---|
| Recommended pairing | Matched modular fabric or leather sofas in dark grey, black or neutral tones | |
| Space size suitability | Medium to large living rooms in apartments and homes | |
| Surface use cases | Display of decorative objects, serving drinks and snacks, holding reading materials | |
| Placement restriction | Not suitable for outdoor use or high-moisture areas like bathrooms |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, performance benchmark for residential use | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface finishes, applicable for lacquer durability validation |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and finish checks | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, required for indoor air quality compliance | |
| GB/T 4893.8-2013 | Surface wear resistance test method for furniture finishes, applicable for surface durability checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and finish checks; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, required for indoor air quality compliance; 3. GB/T 4893.8-2013: Surface wear resistance test method for furniture finishes, applicable for surface durability checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
