Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 4200 x 1600 x 760 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 260 kg | |
|---|---|---|
| Distributed tabletop load | 200 kg | |
| Single-point load | 50 kg | |
| Seating capacity | 12 seats | |
| Floor contact points | 4 pads | |
| Leveling adjustment per foot | 15 mm | |
| LED service life | 30000 hours | |
| Warranty target | 5 years | |
| Meeting capacity | 12 persons | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 25 mm engineered wood board with dark walnut wood-grain laminate | |
|---|---|---|
| Tabletop wear layer | 0.6 mm high-pressure laminate surface | |
| Edge treatment | 2 mm PVC or ABS edge band with champagne accent line | |
| End support panels | Matte champagne painted MDF or particleboard panels | |
| Structural support core | 1.5 mm rectangular steel frame inside the panel bases | |
| Central cable cover | Grey brushed-look plastic or aluminum access cover | |
| Lower fluted fascia | Vertically ribbed thermofoil or painted MDF strip | |
| Ambient lighting | Warm-white LED strip behind translucent acrylic diffuser |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Central 900 x 220 mm access cover routes power, HDMI and network cables from tabletop devices to under-floor outlets | |
|---|---|---|
| Modesty and cable concealment | Full-length 420 mm front fascia blocks knee-level view and conceals underside wiring and junction boxes | |
| Ambient base lighting | Continuous warm-white LED strip illuminates the fluted lower fascia and is intended for low-voltage room power |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive boardroom | Fits 12 participants in a 4200 mm layout for formal meetings, presentations and video-conference equipment | |
|---|---|---|
| High-end conference center | Dark wood top, champagne base and integrated ambient lighting suit premium meeting rooms requiring concealed cabling |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
