Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1800 x 700 x 460 mm | |
|---|---|---|
| tabletop thickness | 51 mm | |
| tabletop corner radius | 40 mm | |
| base height | 330 mm | |
| floor clearance height | 80 mm | |
| cable slot length (each) | 200 mm | |
| cable slot width (each) | 15 mm | |
| cable slot spacing (center to center) | 700 mm | |
| fluted rib width (base) | 8 mm | |
| base cutout width (each) | 400 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| net weight | 28 kg | |
|---|---|---|
| distributed tabletop static load | 151 kg | |
| point load capacity (center of top) | 45 kg | |
| tabletop horizontal surface uniformity | 0.5 mm/m | |
| finish abrasion resistance | 4000 cycles | |
| warranty period | 2 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop substrate | 18mm MDF core with walnut wood grain veneer | |
|---|---|---|
| tabletop surface finish | Matte clear polyurethane coating, 0.1mm film thickness | |
| base outer frame panels | 1.5mm brushed 304 stainless steel with vertical fluting | |
| base internal support structure | 1.2mm powder-coated steel tubular reinforcement | |
| base foot pads | 8mm diameter non-slip rubber glides, 5mm height | |
| cable slot inserts | Brushed stainless steel trim with soft PVC edge gasket | |
| base corner joints | Mitered welded stainless steel seams, polished flush | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| integrated cable routing | Two linear recessed slots pass cords from tabletop to under-base channels | |
|---|---|---|
| floor protection glides | Fixed rubber foot pads prevent scratching hard flooring and stabilize placement | |
| under-clearance floor access | Three open cutouts under the plinth allow robotic vacuum access and cord routing | |
| fixed height support | Plinth base maintains stable lounge-height surface with no moving adjustment parts | |
| surface usability | Low-profile wide top supports display objects, beverage service and remote controls | |
| base ventilation | Open cutouts prevent trapped moisture under the table on hard flooring | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| shipping carton dimensions | 1860 x 760 x 150 mm | |
|---|---|---|
| gross shipping weight | 33 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| residential living room | Placed in front of sofas for beverage, decor and media device placement | |
|---|---|---|
| lounge reception area | Used in hotel or office waiting areas for guest refreshments and reading materials | |
| contemporary open-plan space | Matches modern minimalist, luxury or industrial interior design schemes | |
| media-adjacent placement | Supports soundbars, media devices with routed cords via integrated tabletop slots | |
| low-traffic formal space | Not suitable for high-impact commercial use or outdoor placement |
EU Market Access Requirements* EN Standards
| EN 15372:2008 | Safety, strength and durability requirements for domestic tables, applicable to structural load validation | |
|---|---|---|
| EN 12521:2015 | Strength and stability requirements for residential seating-adjacent tables, applicable to stability testing |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood-composite tabletop performance validation | |
|---|---|---|
| GB/T 4893.8-2013 | Surface abrasion resistance test for wood furniture finishes, applicable to tabletop coating validation | |
| GB 18584-2001 | Formaldehyde emission limit for interior wooden furniture, applicable to substrate material acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood-composite tabletop performance validation; 2. GB/T 4893.8-2013: Surface abrasion resistance test for wood furniture finishes, applicable to tabletop coating validation; 3. GB 18584-2001: Formaldehyde emission limit for interior wooden furniture, applicable to substrate material acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
