Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 1500 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product weight | 210 kg | |
|---|---|---|
| Uniform tabletop static load capacity | 600 kg | |
| Recommended seating capacity | 10 people | |
| Surface abrasion resistance | 2000 cycles | |
| Edge impact resistance | 1.0 m drop | |
| Product service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer tabletop panels | 18mm E1 grade particleboard with grey wood-grain melamine finish | |
|---|---|---|
| Central tabletop inlay | 18mm MDF core with matte dark blue anti-glare melamine writing surface | |
| Table edge banding | 2mm thick grey PVC impact-resistant edge trim | |
| Vertical support bases | 25mm thick particleboard with dual-tone grey and dark blue melamine cladding | |
| Modesty cross panel | 18mm thick dark blue melamine particleboard panel | |
| Cable grommets | Matte black ABS plastic recessed dual-port units | |
| Internal connection hardware | Zinc-plated steel cam locks and fastening bolts | |
| Foot glides | Adjustable nylon leveling glides at each base corner | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated cable management | Two recessed grommets route power and data cables from tabletop to floor | |
|---|---|---|
| Full-length modesty panel | Solid lower panel blocks leg visibility between seated meeting participants | |
| Dual-panel support structure | Thick vertical end supports eliminate need for center legs, providing unobstructed knee space | |
| Leveling adjustment | Adjustable foot glides compensate for up to 15mm of floor unevenness | |
| Anti-glare writing surface | Matte central inlay reduces screen reflection for laptops and presentation materials | |
| Knockdown assembly | Table ships flat-packed for on-site assembly with standard hardware | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | Suits formal meeting spaces for 10person executive meetings and decision-making sessions | |
|---|---|---|
| Medium training rooms | Works for instructor-led group training sessions with laptop and document placement space | |
| Government meeting facilities | Meets durability requirements for high-traffic official meeting rooms with frequent daily use | |
| Open office collaboration zones | Provides large shared work surface for cross-team project discussions and workshops | |
| Conference center rental spaces | Durable neutral finish suits flexible rental spaces for client meetings and small events |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables safety and strength requirements, applies to structural load performance | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for table stability, applies to anti-tip verification during use | |
| EN 312:2010 | Particleboard performance specifications, applies to substrate minimum density and bond strength |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office tables standard, applies to static load, durability and stability test requirements for commercial use |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applies to tabletop structural strength and edge performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, requires E1 grade ≤0.124mg/m³ for all panel components | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applies to static load and stability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applies to tabletop structural strength and edge performance; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, requires E1 grade ≤0.124mg/m³ for all panel components; 3. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applies to static load and stability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
