Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1000 × 750 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed tabletop load | 120 kg | |
|---|---|---|
| Central static point load | 40 kg | |
| Seating capacity | 8 persons | |
| Net table weight | 75 kg | |
| Floor loading pressure | 2.0 kPa | |
| Recommended daily users | 20 persons | |
| Leg leveling adjustment | 10 mm | |
| Surface impact resistance target | 80 N drop test | |
| Seating capacity width | 2300 mm | |
| Reference Static Load | 150 kg depending on category |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 25 mm engineered-wood particleboard core with sealed exposed edges | |
|---|---|---|
| Top surface | White low-gloss laminate or melamine facing | |
| Edge treatment | Matching white PVC or ABS edge banding with straight profile | |
| Leg structure | Powder-coated white steel rectangular posts with upper support rails | |
| Modesty panel | Taupe engineered-wood panel framed by a white border | |
| Foot protection | Black polymer anti-slip pads bonded to each leg base |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | One 100 mm central cable port routes laptop cables from the tabletop to under-table power | |
|---|---|---|
| Seating layout | Three chairs fit along each long side and one at each end for an 8-person meeting setup | |
| Leg privacy | The central 670 mm-high panel screens under-table movement from the opposite seating side | |
| Assembly method | Knockdown construction uses four bolted legs and one central panel, with two-person on-site assembly |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Packaged volume | 0.465 CBM | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Meeting room | Fits an 8-person formal meeting room where users face each other across a central cable-access table | |
|---|---|---|
| Manager consultation area | Suitable for candidate interviews, project reviews, and visitor discussions in a bright executive office |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
