Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 610 x 483 mm | |
|---|---|---|
| Tabletop thickness | 40 mm | |
| End support panel thickness | 50 mm | |
| Right open storage nook dimensions | 300 x 550 x 200 mm | |
| Central under-table floor clearance | 140 mm | |
| Tabletop edge bevel radius | 15 mm | |
| Base panel bottom edge radius | 20 mm | |
| Horizontal connecting apron height | 220 mm | |
| Open knee gap width | 700 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total tabletop distributed static load | 145 kg | |
|---|---|---|
| Integrated side nook static load | 15 kg | |
| Product net weight | 27 kg | |
| Surface scratch resistance rating | 2B | |
| Recommended maximum user weight for edge seating | 100 kg | |
| Warranty period | 12 months | |
| Available color variants | 3 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 18mm E1 grade particleboard core | |
|---|---|---|
| Tabletop surface | Dark brown walnut wood veneer with matte lacquer seal | |
| Base panel core | 25mm E1 grade MDF core | |
| Base panel finish | Matte dark charcoal polyurethane lacquer coating | |
| Structural connectors | Zinc-plated steel cam-lock fasteners with 8mm wooden dowels | |
| Floor protection pads | 3mm thick non-slip rubber pads under all base contact points | |
| Edge banding | 1mm thick PVC edge banding matched to panel finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Integrated side storage nook | Open recessed compartment on right base for books, remotes or decor | |
|---|---|---|
| Floor leveling | Fixed rubber base pads, no adjustable height feet | |
| Surface utility | Smooth sealed top supports drinkware, decor, books and casual serving | |
| Assembly requirement | Knock-down assembly with included hex key and hardware | |
| Safety edge design | Rounded beveled edges on top and base reduce impact injury risk | |
| Floor protection | Rubber contact pads prevent scuffing on hard flooring surfaces | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room | Placed in front of sofas for beverage service, decor and media accessory storage | |
|---|---|---|
| Small apartment spaces | Compact 1200mm length fits open-plan or compact lounge layouts without overcrowding | |
| Lounge reception areas | Suitable for casual office or hospitality lobby seating areas as a low accent table | |
| Recommended surface use | Supports tray service, decorative objects, books, and remote control storage without height adjustment | |
| Care and maintenance | Wipe clean with soft dry cloth, avoid prolonged contact with wet or abrasive materials |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Strength, durability and safety requirements for domestic tables | |
|---|---|---|
| EN 13722:2004 | Furniture - assessment of surface resistance to cold liquids |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for domestic market | |
|---|---|---|
| GB 18584-2001 | Limit of formaldehyde emission for wooden furniture, required for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for domestic market; 2. GB 18584-2001: Limit of formaldehyde emission for wooden furniture, required for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
