Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 3600 x 1400 x 750 mm | |
|---|---|---|
| tabletop thickness | 50 mm | |
| knee clearance height | 680 mm | |
| leg spread width per end set | 800 mm | |
| central support cross section | 120 x 120 mm | |
| cable slot total length | 2400 mm | |
| cable slot width | 80 mm | |
| table end overhang | 300 mm | |
| side overhang | 100 mm | |
| corner radius | 30 mm | |
| adjustable foot pad diameter | 50 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| seating capacity | 12 people | |
|---|---|---|
| distributed static tabletop load | 450 kg | |
| product net weight | 185 kg | |
| finish abrasion resistance | 2000 cycles | |
| leveling adjustment range per foot | 15 mm | |
| warranty period | 5 years | |
| available finish options | 8 colors | |
| frame static load capacity per leg | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop core | E1 grade high-density particleboard core | |
|---|---|---|
| tabletop finish | Light oak melamine laminate surface | |
| edge banding | 2 mm thick PVC edge banding | |
| end support legs | 2 mm thick powder-coated steel splayed legs | |
| central support post | 2 mm thick rectangular powder-coated steel post | |
| cable slot trim | Brushed anodized aluminum slot covers | |
| under-table cable trough | 0.8 mm thick steel wire management trough | |
| leveling feet | Nylon base with steel threaded stud | |
| connection hardware | M8 zinc-plated steel bolts and cam locks | |
| support brackets | 3 mm thick steel mounting plates | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| central cable management | Two parallel recessed slots with removable covers | |
|---|---|---|
| floor leveling | Threaded adjustable foot pads on each leg | |
| knock-down assembly | Flat-pack design with pre-drilled mounting points | |
| modular cable integration | Pre-sized slots compatible with standard desk power modules | |
| stable support design | Three-point support assembly with splayed end legs | |
| impact resistant edges | Rounded PVC edge banding around full table perimeter | |
| non-marring feet | Nylon foot pads on all leg bases | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| assembly note | Engineering, not supplier-measured | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| corporate boardrooms | Seats 12 attendees for formal executive meetings and board sessions | |
|---|---|---|
| large meeting rooms | Sized for team meetings, client presentations and training sessions | |
| conference centers | Suitable for rented event spaces hosting multi-attendee meetings | |
| open office collaboration zones | Provides a large shared work surface for cross-team project work | |
| training facilities | Accommodates instructor-led sessions with multiple connected devices |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for table strength and durability | |
| EN 12521:2015 | Furniture strength, durability and safety for non-domestic tables |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office tables | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture coatings |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 3327-2017: Performance requirements for office tables; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 4. GB/T 4893.8-2013: Surface abrasion resistance test for furniture coatings; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
