Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 4200 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Edge banding thickness | 3 mm | |
| Vertical panel leg width | 120 mm | |
| Knee clearance height under modesty panel | 680 mm | |
| Knee clearance opening width per seating bay | 900 mm | |
| Modesty panel height from floor | 350 mm | |
| Recessed cable cutout dimensions | 100 x 200 mm | |
| Cable cutout spacing along centerline | 1200 mm | |
| Adjustable foot glide adjustment range | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Evenly distributed tabletop static load capacity | 113 kg | |
|---|---|---|
| Recommended seating capacity | 12 people | |
| Laminate surface heat resistance | 120 °C | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Product net weight | 120 kg | |
| Surface stain resistance rating | Grade 5 | |
| Connector shear strength per joint | 800 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | E1-grade MFC engineered wood | |
|---|---|---|
| Tabletop surface | Light wood grain thermofused laminate | |
| Tabletop edge | 3mm matching ABS impact-resistant edge banding | |
| Support legs and modesty panels | E1-grade MDF with matte off-white powder-coated paint | |
| Internal support frame | 1.5mm thick rectangular steel tube | |
| Leveling glides | Nylon base with steel threaded screw | |
| Hardware connectors | Zinc-plated steel cam locks and confirmation screws | |
| Cable cutout trim | Matte ABS plastic recessed grommet trim | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management | Three recessed cutouts route power/data cables from tabletop to floor through base channels | |
|---|---|---|
| Leveling adjustment | Threaded nylon foot glides adjust 10mm to compensate for uneven floor surfaces | |
| Seating access | Four open knee bays provide unobstructed legroom for seated users on both table sides | |
| Modesty panel coverage | Low horizontal panels between legs block direct view of seated users' legs without blocking knee room | |
| Power module compatibility | Cutouts accommodate standard 3-outlet, 2-USB, 1-HDMI, 1-RJ45 integrated conference modules | |
| Assembly structure | Knock-down flat-pack construction requires on-site assembly of top, base panels and hardware | |
| Surface maintenance | Non-porous laminate surface allows wipe-clean disinfection for shared meeting room use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | Fits 12 meeting participants for executive board meetings, video conferences, and team presentations | |
|---|---|---|
| Training and seminar spaces | Stable flat surface supports laptops, training materials, and shared presentation equipment | |
| Hybrid meeting facilities | Integrated cable cutouts support AV equipment, video conferencing hardware, and device charging for remote meetings | |
| Public sector and enterprise meeting spaces | Commercial-grade construction withstands daily frequent use in high-traffic shared work environments |
EU Market Access Requirements* EN Standards
| EN 15372:2016 | Furniture – Strength, durability and safety for non-domestic tables | |
|---|---|---|
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, referenced for base stability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office Furnishings – Desk Products, standard for table load, stability and durability |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade ≤0.124mg/m³ requirement |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety and finish quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade ≤0.124mg/m³ requirement; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
