Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3200 × 1200 × 760 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 800 kg | |
|---|---|---|
| Product net weight | 185 kg | |
| Recommended seating capacity | 6 persons | |
| Desktop surface abrasion resistance | 1000 cycles | |
| Warranty period | 3 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | 0.6mm thick walnut wood veneer over 18mm MDF core | |
|---|---|---|
| Support frame and legs | Solid rubberwood with matte clear lacquer finish | |
| Decorative lattice panels | Solid wood slat inserts with four-lobed cloud cutout | |
| Central modesty panel | 18mm engineered wood with matching wood veneer finish | |
| Side cabinet internal structure | 15mm plywood carcass with wood veneer lining | |
| Table edge profile | Solid wood bullnose edge with rounded corners | |
| Foot rail frame | Solid wood rectangular section frame on each support cabinet | |
| Finish coating | Matte UV-cured lacquer with low VOC emission | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Worksurface layout | Continuous flat rectangular desktop for meeting document and device placement | |
|---|---|---|
| Cable management | Recessed central cable channel with removable cover for wiring routing | |
| Side support storage | Closed cabinet compartments on both left and right ends for supply storage | |
| Leg room configuration | Central open knee bay free of cross braces for unobstructed seated movement | |
| Surface usability | Scratch-resistant matte finish to reduce glare during meetings | |
| Structural stability | Dual side cabinet supports to eliminate desk wobble during use | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive meeting rooms | Fits formal executive conference spaces for 6-person management meetings | |
|---|---|---|
| Private executive offices | Serves as a large executive desk for senior leadership workspaces | |
| Tea room reception areas | Works as a large tea table for formal business reception in traditional style offices | |
| High-end club meeting spaces | Suitable for private club meeting areas requiring traditional Chinese design elements | |
| Traditional style corporate spaces | Pairs with matching New Chinese style office chairs and display cabinets for coordinated furnishing |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables safety and strength requirements, applicable for structural load verification | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for surface resistance to abrasion, applicable for desktop finish inspection | |
| EN 717-1:2004 | Wood-based panels formaldehyde emission determination, applicable for material compliance |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products durability and safety standard, applicable for commercial office performance testing |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wood furniture, applicable for formaldehyde emission testing | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for engineered wood core material inspection |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality inspection; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wood furniture, applicable for formaldehyde emission testing; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable for engineered wood core material inspection; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
