Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 38 mm | |
| Edge banding thickness | 3 mm | |
| Knee clearance height under tabletop | 680 mm | |
| Knee clearance span between end supports | 2000 mm | |
| Modesty panel height | 620 mm | |
| End support leg width | 150 mm | |
| Central cable port dimensions | 300 x 80 mm | |
| Floor clearance under modesty panel | 100 mm | |
| Foot cap accent height | 20 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Distributed static tabletop load capacity | 120 kg | |
|---|---|---|
| Recommended seating capacity | 8 people | |
| Surface abrasion resistance | 2000 cycles | |
| Leveling glide adjustment range | 15 mm | |
| Net product weight | 78 kg | |
| Product warranty | 10 years | |
| Edge impact resistance | 30 N | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | E1 grade engineered particleboard | |
|---|---|---|
| Tabletop surface finish | Thermofused light oak look melamine laminate | |
| Tabletop edge trim | 3mm thick matching PVC edge banding | |
| End support panels | 18mm thick wood-composite panel with off-white matte finish | |
| Central modesty panel | 18mm thick wood-composite panel matching off-white base finish | |
| Leg base accent caps | Solid wood-tone laminate trim matching tabletop finish | |
| Leveling glides | High-density nylon adjustable foot pads | |
| Cable port trim | Brushed silver ABS plastic grommet frame | |
| Hardware fasteners | Zinc-plated steel assembly hardware | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Centered rectangular top grommet routes cords from tabletop to under-table space | |
|---|---|---|
| Under-table cable routing | Open cavity behind modesty panel allows concealed cable runs between endpoints | |
| Floor leveling adjustment | Nylon glides at each leg base rotate to adjust height and stabilize on uneven floors | |
| Fixed work surface height | 750 mm height is optimized for standard office task chair seated use | |
| Knee obstruction design | Full modesty panel provides visual privacy without blocking seated leg movement | |
| Modular power compatibility | Central cable port accommodates retrofit power/USB data modules up to 300mm width | |
| Floor protection | Non-marking nylon glides prevent scuffing on hard flooring and carpet | |
| Assembly connection | Cam-lock fasteners connect panels for rigid knock-down assembly | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Corporate boardroom use | 8-person seating capacity for formal meetings and executive discussions | |
|---|---|---|
| Training room deployment | Stable flat worksurface supports laptops, training materials and shared devices | |
| Modern open-plan office setting | Light wood and off-white two-tone finish complements neutral contemporary office decor | |
| Hybrid meeting setup compatibility | Central cable port supports conference microphones, power adapters and AV equipment | |
| Government/enterprise meeting space | Commercial-grade panel construction withstands daily frequent use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for commercial work surfaces | |
|---|---|---|
| EN 15372:2016 | Furniture, strength, durability and safety for non-domestic office tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office tables, performance and safety standard for desk products, applicable load test reference |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and finish quality | |
|---|---|---|
| GB/T 3327-2017 | Performance test methods for furniture tables and desks, applicable to static load testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade substrate requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and finish quality; 2. GB/T 3327-2017: Performance test methods for furniture tables and desks, applicable to static load testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade substrate requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
