Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3000 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Leg diameter | 76 mm | |
| Knee clearance height | 715 mm | |
| Long-side leg spacing | 1200 mm | |
| Edge bevel radius | 30 mm | |
| End overhang length | 300 mm | |
| Side overhang depth | 100 mm | |
| Leg splay angle from vertical | 18 degrees | |
| Floor contact pad diameter | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Net product weight | 100 kg | |
|---|---|---|
| Tabletop static load capacity | 600 kg | |
| Seating capacity | 10 people | |
| Surface scratch resistance rating | 2000 cycles | |
| Expected service life | 5 years | |
| Per-seat weight capacity | 100 kg | |
| Edge impact resistance | 3 mm | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | High-density MDF core | |
|---|---|---|
| Tabletop surface | Sliced walnut wood veneer, matte UV-cured lacquer finish | |
| Table edge banding | Solid walnut wood edge, 3mm thick, matching veneer finish | |
| Leg construction | Brushed 304 stainless steel cylindrical tube, 76mm diameter, 1.5mm wall thickness | |
| Leg base hardware | Carbon steel mounting plates, 5mm thick, powder coated matte black | |
| Floor glides | Nylon non-marking adjustable height glides, M8 thread | |
| Joint connectors | Zinc-plated steel cam lock and bolt hardware | |
| Surface sealant | Low-VOC matte polyurethane lacquer, 2 coat application | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Height adjustability | Fixed 750 mm working height, no electric or manual height adjustment | |
|---|---|---|
| Floor leveling | 10 mm vertical adjustment range via nylon glides | |
| Cable management compatibility | Pre-drilled 80 mm cable grommet positions at table center | |
| Assembly type | Knock-down construction, legs attach to pre-installed top mounting plates | |
| Modular expandability | Compatible with matching extension sections for longer boardroom configurations | |
| Surface maintenance | Stain-resistant matte finish, wipe-clean with neutral office cleaning agents | |
| Mobility design | Fixed non-wheeled base, intended for permanent placement in boardrooms | |
| Seating access | Open under-table clearance with no cross-bracing blocking knee space | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | Formal executive meeting spaces for up to 10 person board meetings | |
|---|---|---|
| Executive office meeting areas | Adjacent meeting zones in senior leadership private offices | |
| Client meeting suites | High-end client reception and presentation spaces | |
| Co-working meeting spaces | Premium reserved meeting rooms in flexible office facilities | |
| Training rooms | Formal presentation spaces for corporate training sessions |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable for office work tables safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Applicable for office furniture conference tables test methods |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable for desk products performance and safety standard | |
|---|---|---|
| ANSI/BIFMA e3-2019e | Applicable for furniture sustainability standard for environmental claims |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden office furniture | |
|---|---|---|
| GB/T 3327-2021 | Applicable for office table mechanical performance requirements | |
| GB 18584-2001 | Applicable for indoor decoration material formaldehyde emission limits |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden office furniture; 2. GB/T 3327-2021: Applicable for office table mechanical performance requirements; 3. GB 18584-2001: Applicable for indoor decoration material formaldehyde emission limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
