Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 3200 x 1400 x 750 mm | |
|---|---|---|
| tabletop thickness | 50 mm | |
| leg diameter | 120 mm | |
| under-table knee clearance height | 680 mm | |
| knee clearance depth (front edge to apron) | 450 mm | |
| central cable channel length per section | 1000 mm | |
| central cable channel width | 120 mm | |
| modesty panel height | 350 mm | |
| edge radius (rounded tabletop corners) | 60 mm | |
| leg spacing (center to center) | 1200 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| net weight | 185 kg | |
|---|---|---|
| distributed tabletop static load | 500 kg | |
| seating capacity | 10 people | |
| surface abrasion resistance | 2000 cycles | |
| adjustable foot pad adjustment range | 15 mm | |
| structural warranty | 10 years | |
| cable channel port capacity per section | 6 ports | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop core | E0-grade MDF core | |
|---|---|---|
| tabletop surface | Light oak wood veneer with matte acrylic lacquer | |
| leg construction | Solid hardwood core with cream matte lacquer finish | |
| modesty/apron panels | 18mm MDF with matching cream matte lacquer | |
| cable channel covers | Matching veneer MDF with removable brushed aluminum inserts | |
| under-table wire management | 0.8mm thick cold-rolled steel wire trough | |
| hardware connectors | Zinc-plated steel cam locks and bolts | |
| adjustable foot pads | Nylon base with steel threaded stem | |
| finish coating thickness | 0.15mm | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| central cable management | Two longitudinal recessed channels with removable covers | |
|---|---|---|
| leveling adjustment | Threaded adjustable foot pads on each leg | |
| knockdown assembly | Flat-pack design with pre-drilled connection points | |
| seated knee access | Unobstructed open bays between all three leg sets | |
| cable port customization | Modular inserts for power, USB, HDMI, network, and audio ports | |
| surface protection | Matte scratch-resistant lacquer finish | |
| edge safety | Fully rounded beveled tabletop edges | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| corporate boardrooms | Fits 10-person meeting spaces for executive strategy sessions and board meetings | |
|---|---|---|
| training facilities | Supports instructor-led training with integrated power for participant devices | |
| co-working meeting spaces | Provides flexible shared meeting space with accessible cable management for laptops and AV gear | |
| government meeting rooms | Meets commercial durability requirements for high-traffic public sector meeting spaces | |
| modern open-plan offices | Complements light wood/neutral palettes for collaborative work zones |
EU Market Access Requirements* EN Standards
| EN 15372:2016 | Commercial office furniture safety, strength, and durability requirements for meeting tables | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability, and stability requirements for non-domestic seating/table use |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E0-grade core material verification | |
| GB/T 4897.3-2003 | Particleboard/MDF performance requirements for furniture use, applicable for tabletop core testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety and finish quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E0-grade core material verification; 3. GB/T 4897.3-2003: Particleboard/MDF performance requirements for furniture use, applicable for tabletop core testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
