Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1220 x 750 mm | |
|---|---|---|
| Tabletop thickness | 86 mm | |
| Under-table knee clearance height | 660 mm | |
| Central cable raceway width | 150 mm | |
| Trapezoidal pedestal base width (floor contact) | 480 mm | |
| Trapezoidal pedestal base height | 710 mm | |
| Per person seating space per side | 600 mm | |
| Edge bevel radius | 30 mm | |
| Distance between two pedestal supports | 1200 mm | |
| Silver edge trim thickness | 2 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed tabletop static load capacity | 300 kg | |
|---|---|---|
| Net product weight | 134 kg | |
| Seating capacity | 8 people | |
| Surface abrasion resistance | 2000 cycles | |
| Pedestal base lateral stability load | 150 kg | |
| Adjustable glide vertical adjustment range | 15 mm | |
| Warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 25mm E1 grade particle board | |
|---|---|---|
| Tabletop surface | 0.6mm scratch-resistant melamine laminate with dark wood grain | |
| Pedestal base core | 38mm E1 grade MDF slab | |
| Edge trim | Anodized aluminum alloy | |
| Central cable raceway cover | Matte black ABS plastic | |
| Floor glides | Nylon with felt bottom pads | |
| Connection hardware | Zinc-plated steel cam locks and bolts | |
| Table edge banding | 2mm PVC edge banding | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central cable management raceway | Full-length recessed channel routes power and data cables along table center | |
|---|---|---|
| Adjustable floor glides | Rotating pads level table on uneven floors without damaging flooring | |
| Knockdown assembly | Flat-packed components ship dis-assembled for reduced logistics cost | |
| Optional power/data module compatibility | Raceway accepts standard modular power outlets and USB ports for retrofit | |
| Stain-resistant surface | Laminate finish resists liquid spills from coffee, water, and office supplies | |
| Perimeter seating clearance | 300 mm leg depth clearance around all table sides for ergonomic seated use | |
| Cable pass-through to floor | Open channels inside pedestal bases route cables from raceway to floor outlets | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Corporate boardrooms | Seats 8 for executive meetings, board reviews, and client presentations | |
|---|---|---|
| Open office collaboration zones | Provides central work surface for team projects and laptop-based work | |
| Training facilities | Durable laminate surface withstands frequent daily use for employee training | |
| Executive reception meeting areas | Coordinated aesthetic matches modern leather office lounge seating visible in scene | |
| Hybrid meeting spaces | Supports installation of video conferencing equipment and power outlets in central raceway |
EU Market Access Requirements* EN Standards
| Office furniture safety requirements | EN 527:2011 | |
|---|---|---|
| Formaldehyde emission class | EN 312:2010 | |
| Surface reaction to fire | EN 13501:2007+A1:2009 |
US and Canada office-furniture standards
| Table structural performance | ANSI/BIFMA X2021 | |
|---|---|---|
| Static load test | ANSI/BIFMA X2021 |
Standards applicable to China-market projects
| Tabletop formaldehyde emission | GB/T 17657 | |
|---|---|---|
| Furniture structural stability | GB/T 10357.1 | |
| Surface wear resistance | GB/T 17657 | |
| Hardware durability | GB/T 17657 |
This product must meet the following technical requirements: 1. Tabletop formaldehyde emission: GB/T 17657; 2. Furniture structural stability: GB/T 10357.1; 3. Surface wear resistance: GB/T 17657; 4. Hardware durability: GB/T 17657; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
